Specifications
1. flat waterproof electrical push button switch with LED2. CCC,CE ,ISO9001:2008,IAF,UKAS
3. Yellow Supplier by CHINT
Description
These are our company's flat waterproof electrical push button switch with LED models in the picture , you can add X before the flat waterproof electrical push button switch with LED models. If you want one flat waterproof electrical push button switch with LED for sample ,please contact us .thank you.
| Elucidation | Color | Contact Type | Reference | ||
|
|
white | |
1NO | B2-BW3161 |
| green | 1NC | B2-BW3361 | |||
| red | 1NO | B2-BW3462 | |||
| yellow | 1NO | B2-BW3561 | |||
| blue | 1NO | B2-BW3661 | |||
|
white | |
1NC | B2-BW3171 | |
| green | 1NO | B2-BW3371 | |||
| red | 1NO | B2-BW3471 | |||
| yellow | 1NO | B2-BW3571 | |||
| blue | 1NC | B2-BW3671 | |||
| flat waterproof electrical push button switch with LED Environment Features | |
| Match a standard | CB14048 5-2008,IEC 60947-5-1 |
| Ambient temperature | -25°c - +55°c |
| Vibration resistance | ≤ 500HZ , amplitude about 1.0mm |
| Shock resistance | ≥10g |
| Protection level | IP40,IP65 |
| flat waterproof electrical push button switch with LED Technical Parameters | |||||
| Nominal insulation voltage Ui(V) | 380V | ||||
| Rated current lth(A) | 10A | ||||
| Rated operational voltage ue(v) | 380 | 250 | 240 | 125 | |
| Rated operationalcurrent le(A) | AC-15 | 2.5 | 3 | ||
| DC-13 | 0.27 | 0.55 | |||
| flat waterproof electrical push button switch with LED LED | ||||||
| Nominal voltage | AC/DC 6V | AC/DC 12V | AC/DC 24V | |||
| AC110V | AC220 | AC380V | ||||
| LED life | ≥ 30000hours | |||||
| LED color |
|
|||||
| Voltage limitation | 0.85Un≤U≤1.1Un | |||||
Our flat waterproof electrical push button switch with LED have waterproof function
Our flat waterproof electrical push button switch with LED use the fireproof material which can protact it from burning
Our flat waterproof electrical push button switch with LED screw is done by environmental protection plating,after the special technology,it is better to stand wear and tear
The flat waterproof electrical push button switch with LED contact is done by silver alloy ,which is riveting full-automatic and the working life is more than one hundred thousand times.
