Help CenterWenzhou Push Button Switch
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
kenaida
Model Number:
XD16
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
kenaida
Model Number
XD16
Mechanical Life
200000 times
Specifications
1.brand:kenaida2.Name:square head button
3.Certificate:CE,ISO9000
tection level:IP40,IP65
5.Lowest price
| Contact Rating | 3A, 250V AC |
| Contact Resistance | 50mΩ |
| Insulation Resistance | 1,000mΩ |
| Dielectric Strength | 1,500V |
| Life Expectancy(Mechanical) | 25,000 for latching, 50,000 for moment |
| Life Expectancy(Electrical) | 100,000 for latching, 1,000,000 for momentary |
| Mechanical Configuration: | latching&momentary |
| Pushbutton Head | round, mushroom, square, rectangular |
| big square, big rectangular | |
| Cap Colors | red, green, yellow, white, blue |
| Input Voltage of Lamp | neon lamp 110V, 220V |
| LED 2V,6V,12V,24V,36V | |
| Package: | 200pcs/box |
| Rate Value | ||||
| Rated Current lth(A) | 5A | |||
| Rated Voltage (V) | 24V | 125V(110V) | 250V(220V) | |
| Direct-Current | 1A | 0.2A | 0.1A | |
| Alternating Current | P.F=1 | 5A | 3A | |
| P.F=0.7 | 3A | 2A | ||
| Performance Characteristics | |||
| Operational temperation | -25°C - +55°C (No frozen) | ||
| Make Airiness around the product | |||
| Operational humidity | 45- 85%RH (No frost) | ||
| Contact Resistance | ≤50MΩ | ||
| Insulation Resistance | ≥100MΩ | ||
| between the contact and the lamp pin | 2000V,AC50HZ,1min | ||
| between the homopolar terminal | 1000V,AC50HZ,1min | ||
| between different terminal | 2000V,AC50HZ,1min | ||
| Endure Dibratility | 50HZ,1.2mm | ||
| Endure Impact | ≥10g | ||
| Life | auto-return button | 1000000 | |
| auto-return button,selector button | 500000 | ||
| emergency stop button , key button | 100000 | ||
| circle | E6-11 |
|
auto-resetting |
| E6-22 | auto-resetting | ||
| normal button Square | E6-11F | auto-resetting | |
| E6-22F | auto-resetting | ||
| rectangle | E6-11J | auto-resetting | |
| E6-22J | auto-resetting |
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2006
Factory Size
1,000-3,000 square meters
Total Employees
101 - 200 People
