Specifications
RF 400W Co2 laser engraving and cutting machineLarge format
Gantry and Galvo system
High speed
Offline Servo control system
RF 400W Co2 laser engraving and cutting machine
|
Technical Parameter | ||
Model No. |
JMSZJJG-130160 |
JMSZJJG(3D)-130250 |
Laser Type |
CO2 RF metal laser tube |
|
Laser Power |
100W / 150W / 200W / 300W / 400W |
|
Working Area |
1300mm×1600mm |
1300mm×2500mm |
Galvo Engraving Area (one time) |
210mm×210mm |
400mm×400mm |
Working Table |
Zinc-iron honeycomb working table |
Strip panel working table |
Processing Speed |
0-360000mm/min |
|
Repeating Location Accuracy |
±0.1mm |
|
Motion System |
Off-line Servo control system, lead-screw driving |
|
Cooling System |
Constant temperature water-chiller |
|
Power Supply |
AC220V ± 5% / 50Hz |
|
Format Support |
AI, BMP, PLT, DXF, DST, etc. |
|
|
Working size and laser power can be customized according to requirement. | ||
Gantry and Galvo Combination Laser Machine
Features:
This laser machine combines two different laser functions together. X-Y Axis Gantry system for large format and high precision cutting; Germany Galvo system for fast and precise engraving. Two systems only share one laser tube and can switch freely. Ball screw transmission ensures the two systems running stable. Galvanometer scanning system for very fast and large pattern engraving. Coherent or Synrad CO2 RF metal laser tube produces high quality laser beam, stable power and long working life. Low use-cost, maintenance-free and high efficiency.
Advantages:
- Cost efficiency by the application of low maintenance technologies and maintenance-free lasers
- Engrave and cut a wide variety of materials
- One machine cutting both metal and non-metal
- Faster speed and higher precision
- Global pioneer for dual core laser processing system
- Particular ultrasonic auto-focus system
- High efficiency engraving and cutting separated system
- High efficiency galvanometer engraving and cutting integrated technology
- International leading laser motion control system
- Auto-nesting
- Fast pattern digitizing
- Complete exhaust and filtering of cutting emissions possible
- Ergonomic loading and unloading system without time-consuming
Application Field
Applicable Materials: Wood, Plywood, Bamboo, MDF, Balsa, Veneer Inlays, Acrylic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Organic Glass, Rubber Sheet, Plastic, Industrial Plastics (PP, PE, PET, PVC, ABS, PA, PS, PC, etc.), Paper, Corrugated Paper, Cardboard, Pressboard, Paperboard, Chipboard, Thin Sheet Metal, etc.
Applicable Industries: Advertising Industry, Advertising Signs, Advertising Letters, Metal Letters, Nameplates, LED light guide panels (LGP), Plastic Industry, Printing & Packing Industry, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Bangles, Badges, Tags, Decorations, Souvenirs, Precise Ornaments, Models, Architectural Models, Furniture Marquetry, Parquet Floors, etc.
