Specifications
Laser Cutting Machine Wood MDF1.CO2 RF metal laser
2.Ball screw driving
3.High speed cutting
4.golden laser software
Laser Cutting Machine Wood MDF
The Outstanding Laser Cutting Advantages Over Traditional Cutting Tools:
- perfectly clean, smooth and precise edges for difficult geometries
- extremely high cutting speed
- ultra-high flexibility
- tool-free (no retooling!!!) and contact-free technology
- easy handling of machine
- feature "nesting" guarantees most efficient use of materials
- highly economical
Whether you are cutting acrylic crafts or signage, whether you are in the field of architecture model or woodworking, whether you are working with paperboard or cardboard…Laser cutting has never been so simple, accurate, and fast! As one of the world’s leading laser manufacturers, GoldenLaser offers a full scope of state-of-the-art laser equipment to deliver quick, clean, quality results for a broad range of industrial laser cutting needs.
JMSCJG-130250DT High Precision CO2 Laser Cutting Machine
Application
Applicable Materials: Perfectly cutting metal and non-metal materials, such as stainless steel, mild steel, carbon steel, acrylic, wood, MDF, plywood, veneer, plastic, Plexiglas, plexiglass, Perspex, PMMA, ABS, rubber, sponge, paper, cardboard, paperboard, cardstock, etc.
Applicable Industries: sheet metal processing, advertising & signs, LED letters, decorative letters, advertising letters, metal sign letters, crafts, decoration, printing and packaging industry, modelling, furniture & floor manufacturing, Parquet, Marquetry and those which are in need of cutting both metal and non-metal materials.
Machine Features
1) Large format working area with steel girder structure.
2) Precision ball screw driving system and servo motor system ensure high cutting precision.
3) Coherent / Synrad CO2 RF metal laser tube produces high quality laser beam, stable power and long working life. Low use-cost, maintenance-free and high efficiency.
4) Strip panel working table reduces contacting area with work pieces, which ensures high quality cutting.
5) Following exhaust system has good air suction performance, saving energy consumption.
6) Smart nesting function enhances utilization rate of processing material.
7) 5 inches LCD CNC system provides online and offline for your choice, easy to use.
8) Wide application. Suitable for cutting metal and non-metal. It is a multi-purpose machine that can cut up to 30mm thick non-metal materials like acrylic and wood and also can cut up to 3mm thick metal sheets.
|
Main Technical Parameter | |
Laser Type: |
Coherent / Synrad CO2 RF metal laser tube |
Laser Power: |
100W / 150W / 200W / 300W / 400W |
Working Area: |
1300mm×2500mm / 1300mm×1600mm / 1300mm×900mm |
Working Table: |
Strip panel working table |
Working Speed: |
Adjustable |
Repeating Positioning Accuracy: |
±0.1mm |
Cooling System: |
Constant temperature water chiller |
Motion System: |
Servo motor, LCD display, Ball screw driving system |
Power supply: |
AC110V-220V 50/60Hz |
Standard collocation: |
Mini air compressor, Automatic control high pressure blow valve |
|
Working size and laser power can be customized according to requirement. | |
Prompt & Good After-sale Service:
1. One year guarantee for the whole set of machines, not including normal replacement of wearing parts.
2. 24 hours technical support by email or calling. When it is necessary, we will send technician to the customer side to solve the problem.
3. User-friendly English manual and CD for machine using and maintaining.
4. Free lifetime upgrading of self-developed English software.
