Specifications
lazer engraver1.dual head laser engraver cutter
2.for wood,acrylic,mdf,paper,plastic
3.high precision,high speed
4.CE,FDA
Laser engraver
Detailed configuration:
A. South Korea patented high speed linear motion guide rail
B. Optical system uses the world’s top USA II-VI laser optic lens
C. Japan imported YASKAWA Servo motor and drive systems
D. GoldenLaser control system
E. Humanized 5 inches LCD control panels
F. Fully enclosed professional cooling water circulation system
G. Complete exhaust and filtering systems of cutting emissions possible
H. Off-line control system. There are a variety of input methods, such as USB flash disk, USB cable transmission and Cable connection. Easy to use. One computer controls multiple laser machines for cost saving.
Technical Parameter:
Control system: |
DSP control system |
Laser type: |
Sealed CO2 glass laser tube |
Working area: |
1250mmX600mm |
Work platform: |
Zinc-iron honeycomb working table (Automatic up and down distance: 0-150mm) |
Laser power: |
65W/80W/100W (for Cutting); 50W (for Engraving) |
Cutting Speed: |
0-48000mm/min |
Engraving Speed: |
0-64000mm/min |
Motion System: |
Offline step motor system |
Cooling System: |
Water cooling and protection system |
Interface: |
Offline 2.0 USB control system, USB cable connection, internet cable connection and U disk copy |
Auxiliary Devices: |
Mini air compressor, 550W exhaust systems |
Repeating positioning accuracy: |
±0.1mm |
Motion system: |
CNC controlling units |
Working voltage: |
AC220V±5% / 50Hz |
Controlling software: |
Original Golden Laser Software |
Graphic format supported: |
BMP,PLT,AI,DXF,DST,JPG,CDR,HPGL,PNG,DSB,GIF,MNG, TIF,TGA,PCX,JP2, JPC,PGX,RAS,PNM,SKA,RAW etc |
Compatible software: |
Auto CAD, CorelDraw X2/X3/X4, Photoshop, etc |
Optional configuration: |
Auto focus system, Rotary engraving system, Double core system, Strip panel working table, Constant temperature water chiller, Servo system |
Machine dimension: |
2.08*1.40*1.30m |
Packing dimension: |
2.18*1.48*1.50m |
Net weight: |
434kg |
Gross weight: |
525kg |
Packing: |
Plywood case |
Related Models: |
JG-7040SG, 700x400mm, 30W/50W/65W |
JG-10060/JGSH-10060,1000X600mm, 65W | |
JG-13070/JGSH-13070, 1300X700mm, 50W/650W/80W/100W | |
JG-13090DT, 1300X900mm, 80W/100W/130W/150W | |
JG-13090SG/JGSH-13090SG, 1300X900mm, 65W/80W/100W/130W | |
CJG-130250DT, 1300X2500mm, 80W/100W/130W/150W/200W |
Specifications:
1.GOLDEN LASER Patent: Dual core laser processing system. Double combined laser heads work alternately. Stable running with separate laser tube/laser power supply makes longer working life of the machine.
2.Engraving and cutting systems can automatically distribute the two laser heads. Two laser heads can be freely switched to the other.
3.With automatic up and down working table, it is suitable for cutting and engraving different thickness materials. It greatly improves working efficiency and processing quality.
4.automatic focus system, ensuring the best focusing and processing effect.
5.Equipped with rotary attachment, it is suitable for engraving on cylindrical objects. Most suitable for engraving cutting double-color board, acrylic, wood, etc.
Application:
Applicable Materials: Wood, Acrylic, Anodized Aluminum, Plywood, MDF, Leather, Glass, Plastic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, ABS Double Color Board, Organic Glass, PVC, Paper, Paperboard, Cardboard, Marble, Bamboo, Balsa, Rubber Sheet, etc.
Applicable Industries: Advertising, Signs, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Precise Ornaments, Souvenirs, Nameplates, Models, Architectural Models, Furniture, etc.
Laser Engraving Cutting Samples:
Golden Laser Exhibitions Worldwide:
High precision Co2 laser engraver for various nonmetal materials
