Rotary Type Plastic Shoe Automatic Injection Moulding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Taiwan, China
Brand Name:
kou yi
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Two Color Rotary Type Plastic Shoes Automatic Injection Moulding MachineNegotiableMOQ: 1 Unit -
Rotary Type Plastic Sole Automatic Injection Moulding MachineNegotiableMOQ: 1 Unit
-
Vertical Plastic Injection Moulding Machine for ShoesNegotiableMOQ: 1 Set
-
Two Color Vertical Type Automatic Plastic Injection Moulding MachineNegotiableMOQ: 1 Set
-
Rotary Type Automatic PU Single Density Injection Moulding MachineNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Taiwan, China
Brand Name
kou yi
Model Number
NSK-286
After-sales Service Provided
Engineers available to service machinery overseas
Rotary Type Plastic Shoe Automatic Injection Moulding Machine NSK-286
PVC Shoes Machinery
Rotary Type Plastic Shoes Automatic Injection Moulding Machine
Even a skilless worker can operate and maintain this machine easily. Special design for feeding screw: cause to a large quantity of production. Auto feeding system control by computer: feed the material precisely and easy to adjust.
| Item | NSK-286 | UNIT |
|---|---|---|
| Screw rod diameter | Ø70 | mm |
| Ejective capacity | 600 | cm³/shot |
| Screw revolution | 0-100 | r.p.m. |
| Motor of spiral oil pressure | 275 | kg-m |
| Motor of oil-pressure pump | 6P x25HP |
kw/pole |
| Mould clamping force | 50 | ton |
| Mould clamping space(max.) | 245 | mm |
| Size of mould available (max.) | 240 x 400 | mm |
| Mould clamping frame | 20 | STATION |
| Electric heating capacity(glue) | 8 | kw |
| Acting oil capacity | 550 | L |
| Machine size | 3700 x 2500 x 1800 | mm |
| Machine weight | 6.4 | ton |
| Gross weight | 6.9 | ton |
| Packing dimension | 4000 x 2040 2200 | mm |
