BT Morse Taper With Drawbar
- qingdao xingang
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Zhongyi | |
| Model Number | BT stand |
Product Description
Specifications
BT morse taper with drawbar1.sizes:BT40xMTB1-45,BT40xMTB2-60, etc
2.AD/B type
3.balanced G6.3/12000rpm,G2.5/20000rpm
BT morse taper with drawbar
1.sizes:BT40xMTB1-45,BT40xMTB2-60, etc
2.AD/B type
3.balanced G6.3/12000rpm,G2.5/20000rpm
4.the specifications is below:
modle no. BTxMT.no.-L1 | L | D | D1 | diagram |
| BT40xMTB1-45 | 110.4 | 25 | 44.45 | 1 |
| BT40xMTB2-60 | 125.4 | 32 | 44.45 | 1 |
| BT40xMTB3-75 | 140.4 | 40 | 44.45 | 2 |
| BT40xMTB3-90 | 155.4 | 40 | 44.45 | 2 |
| BT40xMTB4-95 | 160.4 | 48 | 44.45 | 3 |
| BT40xMTB4-100 | 165.4 | 48 | 44.45 | 2 |
| BT50xMTB1-45 | 146.8 | 25 | 69.85 | 1 |
| BT50xMTB2-45 | 146.8 | 32 | 69.85 | 1 |
| BT50xMTB2-60 | 161.8 | 32 | 69.85 | 1 |
| BT50xMTB3-60 | 161.8 | 40 | 69.85 | 1 |
| BT50xMTB3-75 | 176.8 | 40 | 69.85 | 1 |
| BT50xMTB4-80 | 181.8 | 48 | 69.85 | 3 |
| BT50xMTB4-100 | 201.8 | 48 | 69.85 | 2 |
| BT50xMTB5-100 | 201.8 | 63 | 69.85 | 3 |
| BT50xMTB5-120 | 221.8 | 63 | 69.85 | 2 |
Remarks:
1.See diagram1,when the arbor is being used,it is necessary to fix inner hex screw.
2.See diagram2,when the arbor is being used,it is necessary to fix standard retention knob.
3.See diagram3,when the arbor is being used,it is necessary to fix extension retnetion knob.
4.When place orders,pls indicate the arbor forms.If it need water-in at center and wanter-in at flange side,pls mark it as AD/B.
packaging way:Inner packing is by plastic box.The outer packing is by cartons.Pallet is available upon the customer's request.
Quality: Each product are inspected durding the production.And then rendomly are selceted for inspection by quality-person.We have exported our goods to around the world and get good feebacks.
Shipment way: We can send the goods by sea,air or couirer(DHL,TNT,Fedex etc) according to the customer's requirement.
Our Services and reputation: we have been the supplier at Alibaba for 8(eight) years.
We always keep our promise and are responsible for the problems if occured after sales.Pls be assured.
