Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Processing Machinery Parts > CAT Milling Chuck
CAT Milling Chuck
US$ 10.55 - 21.08
MOQ: 15 Pieces
Key Specifications
Get Latest Price
Brand Name:
zhongyi
Model Number:
CAT er
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao /xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
zhongyi
Model Number
CAT er
Specifications
CAT milling chuck1.Material:alloy steel
2.Balanced G6.3/12000rpm,G2.5/20000rpm
CAT milling chuck:
1.Material: alloy steel
2. Type: A or AD or AD+B
Type A: Without through hole
Type AD: Without through hole for center coolant
Type AD/B: Form AD and Form b, the former is in the center cold, the latter is in the flange plate cold, mat realize central cooling and the side cools two forms the freedoms to transform.
3. When order please indicate the hilt the concrete form. If needs in the center cold and the flange plant cold, please mark AD/B
4.If needs tp provide the balanced hilt, the standard presicion is G6.3/12000rpm, the precise precision is G2.5/20000rpm
| model no. | D | D1 | model no. | D | D1 |
| CAT40xER16-63 | 28 | 44.45 | CAT40xER50-80 | 78 | 44.45 |
| CAT40xER16-70 | 28 | 44.45 | CAT40xER50-100 | 78 | 44.45 |
| CAT40xER16-100 | 28 | 44.45 | CAT50xER16-70 | 28 | 69.85 |
| CAT40xER16-150 | 28 | 44.45 | CAT50xER16-90 | 28 | 69.85 |
| CAT40xER20-70 | 34 | 44.45 | CAT50xER16-100 | 28 | 69.85 |
| CAT40xER20-90 | 34 | 44.45 | CAT50xER20-70 | 34 | 69.85 |
| CAT40xER20-100 | 34 | 44.45 | CAT50xER20-90 | 34 | 69.85 |
| CAT40xER20-150 | 34 | 44.45 | CAT50xER20-100 | 34 | 69.85 |
| CAT40xER25-70 | 42 | 44.45 | CAT50xER20-150 | 34 | 69.85 |
| CAT40xER25-90 | 42 | 44.45 | CAT50xER25-70 | 42 | 69.85 |
| CAT40xER25-100 | 42 | 44.45 | CAT50xER25-100 | 42 | 69.85 |
| CAT40xER25-150 | 42 | 44.45 | CAT50xER25-150 | 42 | 69.85 |
| CAT40xER32-70 | 50 | 44.45 | CAT50xER32-70 | 50 | 69.85 |
| CAT40xER32-100 | 50 | 44.45 | CAT50xER32-80 | 50 | 69.85 |
| CAT40xER32-150 | 50 | 44.45 | CAT50xER32-100 | 50 | 69.85 |
| CAT40xER40-70 | 63 | 44.45 | CAT50xER40-80 | 63 | 69.85 |
| CAT40xER40-80 | 63 | 44.45 | CAT50xER40-100 | 63 | 69.85 |
| CAT40xER40-100 | 63 | 44.45 | CAT50xER50-90 | 78 | 69.85 |
| CAT40xER40-150 | 63 | 44.45 | CAT50xER50-100 | 78 | 69.85 |
