Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Telecommunication FTTH SM 1 32 Optical Splitter China

Telecommunication FTTH SM 1 32 Optical Splitter China

Name: Telecommunication FTTH SM 1 32 Optical Splitter China
Brand: Yuantong
SKU: 133333699
Availability: InStock

Telecommunication FTTH SM 1 32 Optical Splitter China thumbnail-1

Telecommunication FTTH SM 1 32 Optical Splitter China photo-1

US$ 1 - 20 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Sichuan, China

Brand Name:

Yuantong

Model Number:

PLC splitter

Contact Supplier Request Quote Chat Now

Sichuan Yuantong Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen/Ningbo/Chongqing

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Sichuan, China

Brand Name Yuantong

Model Number PLC splitter

Product details

1.PLC (Planar Light-wave Circuit) splitter is fabricated by using silica optical waveguide technology.

2.Good channel-to-channel uniformity, high reliability and small size.Widely used in PON networks 3.1 x N and 2 x N splitters that are tailored for specific applications.

4.Yuantong can provide customized designs to meet specialized feature applications, and also offers modular assemblies that integrated other components to form a full function module.

Technical Specification of Fiber Optic PLC Splitter:

Parameters	1×2	1×4	1×8	1×16	1×32	1×64	1×128
Operating Wavelength (nm)	1260~1650
Fiber Type	G657A1 or customer specified
Insertion Loss (dB)(P/S Grade)	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	16.5/16.9	20.5/21.0	23.8/24.2
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5	2.0	2.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2	0.25	0.3	0.35	0.4
Return Loss (dB)(P/S Grade)	55/50	55/50	55/50	55/50	55/50	55/50	55/50
Directivity (dB)	55	55	55	55	55	55	55
Wavelength Dependent Loss (dB)	0.3	0.3	0.3	0.5	0.5	0.5	0.5
Temperature Stability (-40~85 °C)(dB)	0.4	0.4	0.4	0.5	0.5	0.5	0.5
Operating Temperature (°C)	-40~85
Storage Temperature (°C)	-40~85
Device Dimension (mm)	40×4×4	40×4×4	40×4×4	50×4×4	50×7×4	60×12×4	N/A
Module Dimension (mm)	100×80×10	100×80×10	100×80×10	120×80×18	140×115×18	140×115×18	140×115×18
Mini-Module Dimension (mm)	50×7×4	50×7×4	50×7×4	60×12×4	80×20×6	100×40×6	N/A

Related Products

Packaging & Shipping

FAQ

1.What's your MOQ ?

MOQ just 1KM.

If you have different or special demands , welcome here, we will try to provide the best solution to you.

2. What's certificates do you have?

At now, we has ISO9001, RoHS, SGS, CE, ANATEL,certificates.

We are confident about our cable quality, if you need, we can provide free sample to you test.

3. Does your company is a manufacturer or trading company?

We are absolutely manufacturer, our factory in Chengdu City of Sichuan province China

Warmly welcome to visit our factory!

4. How about your delivery time?

We can delivery cable very fast, take an order and produce has a high efficient in YUANTONG

The actual manufacturing time according to the cable quantity.

5. How to shipping?

For the sample or light cable (less than 45KG), the best choice is by Express.

Few drums not very heavy(more than 45KG to 100KG), by air is the best choice.

For the heavy cable, the best choice is shipping By Sea. Because it's too expensive by air .

6. Can you help to calculate the freight cost?

of course, we can provide the cheapest shipping cost to you or send our freight forwarder information to you contact directly. If you have freight forwarder, they can handle shipping for you.

7. How to know recycle and new jacket materials?

Except for fiber price , the jacket materials is the main factors affecting price .

Some supplier price is crazy , because they use recycle materials in production. How to make out ?

Recycle material : The jacket will have bubble , especially tenacity is very bad , it's easy to tear . So the cable lifetime is short , and fire retardant, cold resistance is very bad .

New material : Tenacity is very good , it's hard to tear . And with good fire retardant, cold resistance .

8. Can you make OEM?

Of course, it's our main business.

Cable Marking/Printing : It can be marking your brand or any printing that you need , except for international famous brand.

9. Can you testing the cable and provide the testing report?

Of course, we have a independent testing lab, can testing most of FO cable and fiber performance.

Testing report can be provided to you or pasted on the every cable drum.

10. Payment term ?

T/T 100% or T/T 30% deposit ,70% against the copy of BL .

For our familiar customer , we can support good credit payments date.
