China Manufacturer Passive Fiber Optic FTTH PLC Splitter
Description
Fiber optic splitter is a device applied in optical fiber systems with one or more input fibers and one or several
output fibers. There are mainly two types of optical splitters. One is fused splitter (FTB Splitter), the other is
Planar Ligthwave Circuits (PLC Splitter). For the fused optical splitter, it can be devided into different rations,
such as 50/50 if the split is even, or 80/20 if 80% of the signal goes to one side and only 20% to the other.
Planar Lightave Circuits (PLC) can not work with different tration rather than it provides an accurate splitting in
high-density output (such as 8, 16, 32, 64 outputs). However, the most common type of fiber optic splitter splits
the output evenly, which is coming out with the same output of light signals. As a result of its great function,
optical splitter is a very important part in passive optic network (PON).
Types of PLC splitter
Bare fiber PLC splitter
Mini tube PLC splitter
ABS PLC splitter
Insert PLC splitter
Rack mounted PLC splitter
Features
1. Low Insertion Loss
2. Low Polarization Dependent Loss
3. High Reliability
4. High Uniformity
5. Outstanding Optical Performance
6. Easy Installation
7. Excellent Environmental Stability and Widely Used
Application
1. FTTH System
2. Cable Television (CATV)
3. Local Aerial Networks (LAN)
4. Passive Optical Networks (PON)
5. Test Equipment
Technical Parameters
Parameters |
1x2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
Operating wavelength (nm) |
1260 - 1560 |
|||||
|
Insertion loss (dB) (S/P grade) |
4.0/3.8 |
7.3/7.0 |
10.5/10.2 |
13.5/13.5 |
16.9/16.5 |
21/21.5 |
Loss uniformity (d/B) |
0.4 |
0.6 |
0.8 |
1.2 |
1.5 |
2.5 |
Return loss (dB)(S/P grade) |
50/55 |
50/55 |
50/55 |
50/55 |
50/55 |
50/55 |
|
Polarization dependent loss (dB) |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.4 |
Directivity (dB) |
55 |
55 |
55 |
55 |
55 |
55 |
|
Wavelength dependent loss (dB) |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
0.5 |
|
Temperature stability (-40 - +85℃) |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
Operating temperature (℃) |
-40 ~ +85 |
|||||
Storage temperature (℃) |
-40 ~ +85 |
|||||
Order Information
a. Two out of the 1310nm, 1490nm and 1550nm operating wavelength can be selected.
b. 1x2, 1x4, 1x6, 1x8, 1x12, 1x16, 1x32, 1x64 configurations of splitters are available.
c. 250um bare fiber, 0.9 loose tube, 2. 0mm or 3.0mm LSZH fiber cables can be selected.
d. The length of input or output fibers can be also customized; 1m length as default.
1.Can you provide free samples for us?
Sure, we can provide the free samples for you, but the shipping cost need be on your account.
2.What’s the lead time for all the goods that I required?
About the 3-4 working days after getting payment,or depending on quantity.
3.What’s the warranty for your products?
Normally it is 2 years for accessories,20 years for optical cables.
4.What’s your payment term?
Usually TT.
5.What’s the MOQ for your products?
1pcs is okay.
