PVC Insulated Copper Conductor Solid Wire, H07V-R

FOB Price

US$ 0.06 - 35 / Meter

5000 Meters(Min. Order)

Port Shenzhen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Yongkuntai
Model Number	BVR	Type	Other, Insulated, copper wire
Application	Heating	Conductor Material	Copper
Conductor Type	Stranded	Insulation Material	PVC

Product Description

PVC Insulated Copper Conductor Solid Wire, H07V-R

1.Range of Application

Building wire is fit for AC rated voltage 450/750V and below of domestic electrical appliances of smaller size motorized tools of instruments of various meters and motorized lighting installations.

2.Service Conditions

Working temperature:Not more than 105oC for RV-105 model.The other no more than 70oC.

3.Model and Name:see table1

Model	Name
RV	Copper Core PVC Insulation Flexible Wire
RVB	Copper Core PVC Insulation Flat Flexible Wire
RVS	Copper Core PVC Insulation Twisted Flexible Wire
RVV	Copper Core PVC Insulation Sheath Round Flexible Wire
RVVB	Copper Core PVC Insulation Sheath Flat Flexible Wire
RV-90	Copper Core Heat-resistak Losc PVC Flexible Wire

4.Specification Size and Technical Data:see table 2

Nominal Section (mm2)	Core Structure No./Dia.(mm)	Max Dia.(mm)	Reference Weight(kg/km)
0.3	16/0.15	2.3	6.4
0.4	23/0.15	2.5	8.1
0.5	16/0.2	2.6	9.1
0.75	24/0.2	2.8	12.2
1.0	32/0.2	3.0	15.1

RV 450/750V

Nominal Section (mm2)	Core Structure No./Dia.(mm)	Max Dia.(mm)	Reference Weight(kg/km)
1.5	30/0.25	3.5	21.4
2.5	49/0.25	4.2	24.5
4	56/0.20	4.8	51.8
6	84/0.30	6.4	74.1
10	84/0.30	8.0	12.4

Other sizes can also be produced as you required.

Our Packing:

Our factory:

shenzhen jixing wire&cable co.,ltd .is a specializing in the production of wire and cable, our products : 0.6/1kv plastic insulation,cross-linked insulated power cable,LSZH cables environmentally friendly,flame retardant cables,fire resistant cables,aluminum cable,branch cable,B series(rated voltage 450/750 and bellow) plastic wire and cable,XLPE wires and specifications. Company has the most advanced testing equipment and production equipement,quality has reached the national and industry standards.

Our customers:

Certification:

Jixing cables:

Shenzhen Jixing Electric Cable & Wire Co., Ltd welcome you!

whatsapp: 18955339397

wechat: 18955339397

contact person: Kevin

contact number: 18123855747
