IACS Approved Hydraulic Bow Thruster/ Azimuth Thruster/ Hydraulic Thruster
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer, Trading Company
Year Established:
2011
Factory Size:
5,000-10,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Propeller for Outboard EngineNegotiableMOQ: 2 Pieces -
Marine CPP Bow ThrusterNegotiableMOQ: 1 Unit
-
Various Marine Thrusters/bow Thruster/azimuth Thruster/main Controllable Pitch PropellerNegotiableMOQ: 1 Unit
-
Electric Bow Thruster/tunnel ThrusterNegotiableMOQ: 1 Unit
-
High Speed Marine GearboxNegotiableMOQ: 10 Sets
Specifications
Our hydraulic bow thruster is with enough hydraulic power to keep the thrust and speed. It's also quiet, reliable, efficient.
hydraulic bow thruster/azimuth thruster has a completed hydraulic system, which includes the motor, pump station, control device, etc.
Specifications for the hydraulic bow thruster/azimuth thruster:
| Type | Propeller Dia. | Max. Thrust | Max.Input Power | Input Speed (rpm) | Propeller Speed (rpm) | Propeller Type | |||
| mm | kN | ton | kW | 60Hz | 50Hz | 60Hz | 50Hz | ||
| TUF15 | 700 | 15.8 | 1.61 | 105 | 1750 | 1450 | 778 | 785 | FP |
| TUF35 | 880 | 34.3 | 3.5 | 241 | 1750 | 1450 | 656 | 666 | FP |
| TUF55 | 1100 | 53.9 | 5.5 | 378 | 1750 | 1450 | 532 | 534 | FP |
| TUF 70 | 1250 | 68.6 | 7 | 465 | 1750 | 1450 | 480 | 483 | FP, CP |
| TUF 90 | 1400 | 88.3 | 9 | 603 | 1750 | 1450 | 429 | 441 | FP, CP |
| TUF 110 | 1550 | 108 | 11 | 745 | 1750 | 1450 | 396 | 393 | FP, CP |
| TUF 135 | 1700 | 132 | 13.5 | 921 | 1170 | 1450 | 356 | 356 | FP, CP |
| TUF 160 | 1850 | 157 | 16 | 1103 | 1170 | 1450 | 331 | 328 | FP, CP |
| TUF 195 | 2050 | 191 | 19.5 | 1327 | 1170 | 980 | 299 | 298 | FP, CP |
| TUF 235 | 2250 | 230 | 23.5 | 1597 | 1170 | 980 | 274 | 273 | FP, CP |
Tunnel Thruster, Hydraulic Thruster, Marine Thruster, Bow Thruster
Hydraulic system for the thruster:
Motor for the Thruster:
