Rubber Propeller Functional Characteristics
· Rudder and thruster in one.
· Rudder propeller can steer in any direction of 360° above the water level
Advantage
· Provide all-around thrust
· Increase the operation flexibility of the vessel
Application
Large tugboat, harbor tug, drilling platform vessel, ocean engineering vessel
Rudder Propeller Installation Type
· Well installation
· Transom installation
· Deck installation
Marine Rudder Propeller Specification
Type | Input Power Max.(KW) | Input Speed Rated.(RPM) | Input Torque Max.(N.m) | Propeller Dia. Max. (mm) | Reduction Ratio | Weight(kg) |
SRP12 | 45 | 2300 | 200 | 500 | 1.93 | 65 |
SRP45 | 100 | 23502500 | 450 | 800 | 2.5 | 190 |
SRP85 | 210 | 2350 | 850 | 950 | 2.68 | 400 |
SRP138 | 260 | 2000 | 1380 | 1100 | 3.01 | 1200 |
SRP180A | 340 | 1800 | 1800 | 1150 | 3.46 | 1450 |
SRP180B | 280 | 1500 | 2.88 | |||
SRP180C | 180 | 1000 | 2.526 | |||
SRP226 | 350 | 1800 | 2260 | 1350 | 3.34 | 2000 |
SRP280 | 480 | 2800 | 1550 | 3.96 | 2100 | |
SRP310A | 580 | 3070 | 1550 | 3.718 | 2500 | |
SRP310B | 1500 | 3800 | 3.002 | 2600 | ||
SRP330 | 620 | 1800 | 3300 | 1600 | 4.04 | 2800 |
SRO330B | 620 | 1500 | 4100 | 3.26 | ||
SRP428A | 735 | 1800 | 4280 | 1600 | 4.35 | 4500 |
SRP428B | 1500 | 5220 | 3.671 | |||
SRP428C | 1000 | 7140 | 2.769 | |||
SRP550 | 920 | 1800 | 5423 | 1800 | 5.059 | 6000 |
SRP1000 | 1000 | 9762 | 2.804 | |||
SRP1150 | 1103 | 11500 | 1800 | 2.775 | 7000 | |
SRP1150A | 750 | 15280 | 2.102 | |||
SRP1450 | 1324 | 1000 | 14800 | 2100 | 3.257 | 17000 |
SRP1850 | 750 | 18500 | 2.44 | 18000 | ||
SRP1850B | 825 | 17900 | 2.68 | |||
SRP1850C | 900 | 16200 | 2.93 | |||
SRP2000A | 1545 | 525 | 30000 | 2200 | 1.925 | 20000 |
SRP2000 | 1471 | 750 | 20000 | 2.74 | ||
SRP2000B | 825 | 18800 | 3.01 | |||
SRP2000C | 900 | 17500 | 3.257 | |||
SRP2000D | 1000 | 16000 | 3.66 | |||
SRP2500A | 1912 | 750 | 31200 | 2450 | 3.32 | 24000 |
SRP2500B | 825 | 28360 | 3.453 | |||
SRP2500C | 900 | 26000 | 3.983 | |||
SRP2500D | 1000 | 26000 | 4.42 | |||
SRP3000A | 2206 | 750 | 31200 | 2650 | 3.32 | 28000 |
SRP3000B | 825 | 28360 | 3.453 | |||
SRP3000C | 900 | 26000 | 3.983 | |||
SRP3000D | 1000 | 26000 | 4.424 | |||
SRP4000A | 3000 | 750 | 42000 | 3200 | 4.41 | 53000 |
SRP4000B | 825 | 38200 | 4.85 | |||
SRP4000C | 900 | 35000 | 5.29 | |||
SRP4000D | 1000 | 32000 | 5.88 |
