Upper Rudder Bearing/ Upper Rudder Carrier
US$ 1 - 1
/ Set
1 Set(Min. Order)
- shanghai
- Money Gram
You May Like
-
CB3282-87 Marine Surface Friction Watertight Upper Rudder Carrier
-
Rapson Slide Type Marine Steering Gear
-
Ship Steering Engine
-
100-2500KN.M Rotary Vane Hydraulic Steering Gear System
-
Marine Hydraulic Rotary Vane Steering Gear/ Dyz-Type Rotary Vane Steering Gear
-
Rotary Vane Marine Steering Gear (heavy Duty Type)
Product Details
| Place of Origin | Chongqing, China | Brand Name | Perpetual | |
| Model Number | CB3282-87 | Part | Other, Bearing |
Product Description
Specifications
Our surface friction watertight upper rudder carrier is designed and manufactured in accordance with the standard of CB*3282-87The Surface Friction Watertight Upper Rudder Carrier is one of the commonest upper rudder carriers used for different ships. The proper diameter of the rudder stock is from 200mm to 600mm.
Technical parameters:
| Dia. Of Rudder Stock | D1 | D2 | D3 | D8 | Connecting Bolt | A | B | C | E | H | T3 | Key Size |
| 200 | 216 | 466 | 670 | 590 | M30×12 | 330 | 80 | 90 | 450 | 20 | 30 | 45×25×80 |
| 220 | 236 | 550 | 790 | 700 | M36×12 | 375 | 85 | 100 | 505 | 20 | 30 | 45×25×90 |
| 240 | 258 | 620 | 860 | 770 | M36×12 | 430 | 90 | 100 | 560 | 20 | 30 | 45×25×90 |
| 260 | 278 | 680 | 920 | 830 | M36×12 | 460 | 95 | 110 | 600 | 20 | 30 | 50×28×100 |
| 280 | 300 | 720 | 960 | 870 | M36×12 | 515 | 90 | 110 | 665 | 20 | 40 | 60×32×100 |
| 300 | 320 | 750 | 1110 | 940 | M42×12 | 545 | 95 | 120 | 705 | 20 | 40 | 60×32×110 |
| 320 | 342 | 780 | 1180 | 1010 | M42×18 | 570 | 100 | 120 | 730 | 25 | 40 | 60×32×110 |
| 340 | 362 | 840 | 1240 | 1070 | M42×18 | 630 | 105 | 130 | 800 | 25 | 40 | 60×32×120 |
| 360 | 384 | 900 | 1300 | 1130 | M48×18 | 690 | 90 | 130 | 880 | 25 | 60 | 60×32×120 |
| 380 | 404 | 960 | 1360 | 1190 | M48×18 | 755 | 95 | 140 | 955 | 25 | 60 | 60×32×130 |
| 400 | 426 | 960 | 1360 | 1190 | M42×12 | 600 | 110 | 140 | 800 | 25 | 60 | 70×36×130 |
| 420 | 446 | 1020 | 1420 | 1250 | M42×18 | 635 | 110 | 150 | 845 | 30 | 60 | 70×36×140 |
| 440 | 468 | 1080 | 1480 | 1310 | M42×18 | 665 | 105 | 150 | 885 | 30 | 70 | 70×36×140 |
| 460 | 488 | 1140 | 1540 | 1370 | M42×18 | 700 | 110 | 160 | 930 | 30 | 70 | 70×36×150 |
| 480 | 510 | 1210 | 1610 | 1440 | M42×18 | 730 | 115 | 160 | 960 | 30 | 70 | 80×40×150 |
| 500 | 530 | 1270 | 1670 | 1500 | M42×18 | 760 | 120 | 170 | 1000 | 30 | 70 | 80×40×160 |
| 600 | 690 | 1450 | 1950 | 1785 | M64×28 | 890 | 140 | 200 | 1300 | 40 | 80 | 100×50×190 |
*Remark: This data sheet is just for reference. We can also manufacture the size according to the requirement or drawing of our client.
