Home > Transportation > Marine Parts > Boat Propellers > Controllable Pitch Propeller

Controllable Pitch Propeller

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, Bronze,brass

Blades:

Contact Supplier Request Quote Chat Now

Chongqing Perpetual Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, Bronze,brass

Blades 4

Specifications

Controllable Pitch Propeller
1. High quality
2. Reasonable price

Controllable Pitch Propeller
1.Power Optional
2.Blades Size Optional
3.CCS ,BV,ABS,NK, KR,DNV,RINA,LR, GL.

Specifications:

1.Power Optional : Max.Power up to 3000hp.
2.Blades Size Optional

3.Diameter of propeller: up to 3300mm

4. Electric motor drive, hydraulic drive or diesel engine drive.
5.Certificates: CCS ,BV ,ABS,NK, KR,DNV,RINA,LR, GL.

PRFORMANCE

To meet the harsh ocean environment, we take full consideration of reliabilities during the hydrodynamic calculation, structural design and material selection, which make our controllable pitch propellers are featured with good reliability, simple configuration and maintenance friendly, etc. The hub is designed with large diameter servo piston, and the hydraulic force of the piston works on the yoke, so as to decrease the work oil pressure required by the hydraulic system.

Combining the test to the propeller design, we apply the large skew propeller and optimal disc ratio solutions to lower down the cavitations and vibration of the propeller, in this way, not only the navigation speed and towing force can be satisfied, but also the operation performance and economical efficiency of the ship is improved.

During the shaft line design, we take account of the negative influence to the shaft strength, vibration and alignment caused by the bending stress load change, propeller stress, gear meshing load and the bending stress of main engine crank shaft, and the calculation result fits more with real work condition.

During the navigation, if the feathering CPP does not work, the blades can be adjusted to the downstream condition to decrease the resistance effectively.

PARAMETER

Hub model	Max blade dia.	Max speed	Transmission's capacity	Thrust
Hub model	(mm)	(rpm)	(kW/rpm)	(t)
TUF39	1670	550	2	12.2
TUF43	1845	530	2.6	15.5
TUF46	1980	500	3.5	20.5
TUF52	2250	450	4.3	24.5
TUF56	2400	390	5.5	28.5
TUF60	2600	390	6.8	33.5
TUF68	2950	280	9.6	42.5
TUF76	3300	230	13.8	51.5
TUF85	3700	230	20.1	62
TUF96	4200	230	27.6	78
TUF102	4350	230	32.8	83
TUF107	4600	230	36.4	92
TUF120	5200	230	54.2	109
TUF135	5900	220	80.6	130
TUF145	6250	200	110.2	140
TUF156	6700	200	160.5	152

HYDRAULIC SYSTEM

Hydraulic system of NCP series CPP is composed of OD box and hydraulic power pack, and the power pack is split into two types: single pump and double pump. The single pump power pack is the standby, main pump is the pump driven by the gearbox. There are two sets of electric pumps in double pump power pack, which can transform between one another automatically.

The OD box can be mounted in front of the gearbox or on the shaft line. These two arrangements of gearboxes are attested to be very reliable and flexible to maneuver.

CONTROL SYSTEM

Remote control system, cooperated with NORIS, is the fully follow-up control system based on PLC, and its main control points are main engine speed, CPP pitch and gearbox clutch-in/out. It can not only display the current work condition of the ship, it can also carry out the remote failure diagnosis and emergency treatment. This type of control system is designed with good expansibility, friendly human-computer interface, high reliability and easy operation, etc, and has been widely used all types of vessels.
