Specifications
Low power, intense vibrating forceAuto-cleaning system of mesh
ISO9000;2000
Vibro Screen/Sieve
We have processed various powders of diameters from 50m to 625 m and accumulated abundant experience about UCS ultrasonic high-energy screen. And finally we designed such a screen that can sweep the frequency automatically.
Parameters
|
Param. Type |
Motor Power |
Motor electric Current |
Motor vibrating Force |
Diameter & Height(mm) |
Sono Frequency |
SY-400 |
0.1kw |
0.32A |
2500N |
400&660 |
36.5KHz |
SY-500 |
0.2kw |
0.65A |
5000N |
500&745 |
36.5KHz |
SY-600 |
0.2kw |
0.65A |
5000N |
600&875 |
36.5KHz |
SY-800 |
0.5kw |
1.37 A |
10KN |
800&895 |
36.5KHz |
SY-1000 |
0.7kw |
1.96 A |
16KN |
970&945 |
36.5KHz |
SY-1200 |
0.7kw |
1.96 A |
16KN |
1170&995 |
36.5KHz |
SY-1500 |
1.5kw |
3.76 A |
25KN |
1470&1095 |
36.5KHz |
- Ultrasonic vibration is at the speed of 36000 times/s .
- Anti-clogging system of mesh cloth, so longer the mesh cloth is .
- Solving such issues as static electricity, absorbate, sticking, clogging and so forth.
- Sweep the frequency automatically,
- Applicable to sieve the material of 20m300m, and especially effective to the tricky materials
- Applicable to sieve the material of 20μm~300μm, and especially effective to the tricky materials
- Ultrasonic self-cleaning function can prevent the sieve cloth of 50~625m being plugged, and prolong the life span of sieve mesh.
- Can exactly separate micro particles of similar size
- No hot spots. It meets the demanding of controlling the temperature of materials, such as medicine and its original materials, thermosetting coatings and so on.
Henan xinxiang sanyuantang MachineCo., Ltd. is a research-centric technology-based professional manufacturer of ultrasonic vibro sieve. We have a team with strong research capability. The technologies of our products have always been at the cutting edge (forefront) of the industry.
With "Navector Sieving Expert and Quality Commitment" as the core of our brands, " To be the Navigator of Sieving Industry " as the business philosophy, our company carries manufacture, supply, ...
