Help CenterThree-Dimension Vibratory Filter for Slurry
Related Products
Specifications
SYseries vibrated filter is one of precised powder griddle,low noise ,high efficiency,need only 3~5 minutes to rapidly replaceSY series vibrated filter is one of precised powder griddle,low noise ,high efficiency,need only ~5 minutes to rapidly replace the griddle,all closed structure.Used to filter particles,powder and mucilage
You can use a sifter in a quality assurance program to scalp material, remove fines, or grade material. You can also use a sifter to grade material in a manufacturing process.
- For scalping, the sifter's most common quality assurance application, the sifter removes oversize or foreign materials. These can be agglomerates and lumps in materials such as flour mixes, as well as foreign materials such as insects, bin wall scale and flakes, moldy material, or tramp metal.
- For removing fines, the sifter removes undersize and dedusts the material to meet final product specs. This is useful for friable materials that give off fines or other materials that release fines in response to excessive or rough handling. Typical applications include removing fines from dried herbs, spices, sugar, and granular pharmaceuticals.
- For grading, the sifter controls both oversize and undersize in your material. A common example for quality assurance is grading sugar to simultaneously remove the lumps and fines. In manufacturing, in addition to removing coarse oversize and fines, grading can produce multiple intermediate particle sizes in materials such as wood particles or polystyrene beads.
In each of these uses, sifting provides another benefit: Passing through the screen aerates the material, which gives it a more uniform bulk density for subsequent processing and handling steps.
- Screeners range in size from 24” to 60”
- Wide range of screen meshes down to 25 microns
- Perfect for both wet and dry applications
SY round sifter |
SY-350 |
SY-515 |
SY-650 |
SY-800 |
SY-1000 |
SY-1500 |
Capacity |
40-500 |
60-600 |
80-800 |
150-1200 |
300-2000 |
350-2800 |
Meshes |
12-200 |
12-200 |
12-200 |
12-200 |
5-325 |
5-325 |
Power Kw |
0.55 |
0.55 |
0.55 |
0.75 |
1.5 |
2.2 |
Speed rpm |
1380 |
1370 |
1370 |
1500 |
1500 |
1500 |
Overall dimensions |
540*540*1060 |
710*710*1290 |
880*880*1350 |
1000*1000*1400 |
1100*1100*1200 |
1600*1600*1200 |
Weight Kg |
100 |
180 |
250 |
300 |
350 |
400 |
CS |
CS-500*1200 |
CS-500*1500 |
CS-600*1200 |
CS-600*1800 |
CS-800*1600 |
CS-800*2500 |
capacity |
150-300 |
200-350 |
200-400 |
300-550 |
400-750 |
500-1000 |
