Specifications
simple type of film blowingmachine1) applicable for PE,LDPE,LLDPE, HDPE
2) more economic
3) good quality
SJ45(50)-600/700 Mini Type Film Blowing Machine
Characteristics:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity.
Appliable:
It is applied to blowing the plastic films like low density polythene (LDPE), high density polythene(HDPE) and linear low density polythene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
Model |
SJ-45/FM650 |
SJ-50/FM850 |
Screw Diameter |
45mm |
50mm |
Screw Ratio |
L/D28:1 |
L/D28:1 |
Screw Speed |
10-100r/min |
10-100r/min |
Power of Main Motor |
11KW |
15KW |
Max. Extrusion output |
35kg /h |
50kg /h |
Max. Folding Width of Film |
600mm |
800mm |
Single-sided Thickness of Film |
0.006 -0.10mm |
0.006 -0.10mm |
Lifting Range of Auxiliary Machine |
700mm |
700mm |
Total Power |
22Kw |
28Kw |
Weight of Machine |
2200kg |
2600kg |
Overall Dimensions( L × W × H ) |
4000×2000× 2800mm |
4600×2300× 3800mm |
