TY-Four-meter Developing Machine
Process flow:
Feeding → Developing 1 → Developing 2 → Pump washing 1/2/3/4 → DI Water washing → Blot up → Cold wind drying → Hot wind drying → Discharge
Features:
1. This machine is used for the developing of precision image.
2. Each spray pipe has its own pressure adjustments and special nozzle layout, which can ensure the precision graphics and fine lines.
3. The filtering device can avoid the defects because of the surface residual fragments.
4. The horizontal swing spray system used with special nozzle is featured with even spray and stable water flow to reach perfect developing effect.
Main technical parameter:
1 |
Size of Machine |
L10745×W1800×H1980mm |
2 |
Working Height |
900mm |
3 |
Working Width |
640mm |
4 |
Wheelbase |
35mm |
5 |
Running Speed |
0.1-5m/min |
6 |
Power voltage |
Three-Phase Four-Wire 380 V 50 HZ |
7 |
Total power of the machine |
75KW |
8 |
Size of minimal board |
80mm*60mm |
9 |
Thickness of outputting board |
0.075-2.5mm |
10 |
Running water consuming |
20-32L/min |
