Double-side Precision Etching Stripping Machine
- 10 Set / Sets per Month
- Shanghai Port
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Stainless Steel Double Kitchen Sink Middle Weld Seam Rolling Machine
- Stainless steel handmade sink hydraulic power of light direct press
- Stainless steel handmade sink R corner press machine Electrical box R corner press machine
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | TIAN YI | Model Number: | TY-DPE-1 |
After-sales Service Provided: | No overseas service provided |
Product Description
Double Precision Etching Stripping machine
Process:
Feeding→ Etching 1 → Etching 2→Recycle Water Washing→Urban Water Washing→Blot Up→Check→Soak→Spraying Stripping→Recycle Water Washing→Urban Water Washing→Blot Up→Hot Air Drying→Discharge
Main Parameter:
1.Worktable Width:640mm (Effective600mm)
2.Worktable Height:900±25mm
3.Convey Speed:0.5-5m/min(Frequency control)
4.Convey Wheel Base:35mm
5.Workpiece Size:Maximum 600mm*Any longer
Minmum 80mm*60mm
6.Workpiece Range:FPC(Flex Circuits)≥0.075mm PCB≥0.8mm
7.Outer Size: L17200*W2400*H1980
Advantage:
- Accept the touched monitor with PLC matched advanced man-machine interface as controller,which more easy to operation,more hommization.
- Accept the special side window sealing structure,avoid liquid & gas overfall.
- Accept corrosion resisting diaphragm gauge invidually to control the spraying pressure,control the etching speed from up to down.
- Top & bottom spraying pipe at etching section use the advanced alternative arrangement style,reduce the transverse distance between each spray nozzle,increase the spraying contact ratio and even,enhance the etching effect obviously.
- All the medicinal liquid tank and recycle water tank be designed including double filtering set both with auxiliary cylinder style & outlay style.
- Drain off water & air-out & winding dispacement be collected together,more beautiful appearance,more tidy environment.
