Help CenterPP Pleated Filter Cartridge/Pre Filtration Pleated Cartridge PP Water Filter Cartridge
Related Products
-
Polyester Cellulose Pleated Filter Cartridge,swimming Pool Filter CartridgeUS$ 0.1 - 1MOQ: 10 Pieces -
1 Micron Polyester Pleated Water Filter CartridgesUS$ 4 - 5MOQ: 1 Piece
-
Washable and Resuable Whirlpool Compatible Water Filter CartridgesUS$ 0.8 - 2MOQ: 10 Pieces
-
Big Blue Pleated Washable Sediment Water FilterUS$ 4 - 5MOQ: 1 Piece
-
10 Inch Micron pp Pleated Alkaline Water Filter Cartridge Water Filtration Cartidge/pp Pleated Filter CartridgeUS$ 2 - 3MOQ: 20 Pieces
Material Of Construction |
Filter media |
Polypropylene |
|
Support Layers |
Polypropylene |
|
Micron rating |
0.1,0.2,0.45,0.65,1.0,2.0,3.0,5.0,10,30,50,70,100 μm |
|
Inner core |
Polypropylene |
|
Outer cage,End Cap |
Polypropylene |
|
Seal Method |
Thermal Bonded,No Adhesives |
|
O-ring/Gaskets |
EPDM,Slicone,Buna,Viton |
Cartridge Dimensions |
Outer Diameter |
69mm(2.75”) |
|
Inner Diameter |
28mm(1.10”) |
|
Length(Based on DOE End Cap) |
10”-254mm,20”-508mm,30”-762mm,40”-1016mm |
|
Filtration Area(m2) |
0.65m2 per 10” |
Operating Conditions |
Normal Operating Temperature |
Up to 65℃ (140℉) |
|
Max.Operating Temperature |
90℃ (194℉) at P≤1.0 bar (14.5psi) |
|
Forward Flow Direction |
4.2 bar (60 psi) at 25℃ (77℉) |
|
Reverse Flow Direction |
2.1 bar (30psi) at 25℃ (77℉). |
|
PH Value Compatibility |
1-14 |
|
Sterilization Temperature Time |
Steam Sterilization for 30 minutes at 121±2 ℃, 100 cycles, Autoclave 30minutes (optional)
|
Cartridge Safety |
Endotoxin |
<0.25 EU/ml |
|
Extractables |
0.03g / 10" |
Characteristics
Low differential pressure.
Low-cost.
High flow rates.
Long service life.
Ultrasonic welding and without adhesive.
100% integrity test for filter cartridge.
Widely filter precision and selectivity, available for various situations.
Broad chemical compatibility, and good chemical stability, acid-proof, alkali-proof, ethanol-proof, ketone-proof, DMF-proof, phenol-proof and other chemicals.
Q1. Can I have a sample order for filter cartridge?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks after the payment.
Q3. Do you have any MOQ limit for filter cartridge?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for filter cartridge?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on filter cartridge product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
