Help CenterPP Membrane Pleated Filter Cartridge for Pre-filtration or RO System,DI Water
Related Products
-
Ptfe Pleated Filter Cartridge for Compressed GasUS$ 0.3 - 25MOQ: 1 Piece -
Ptfe Pleated Filter Cartridge for Acid BathUS$ 0.3 - 25MOQ: 1 Piece
-
Ptfe Pleated Pharmaceutical Filter Cartridge for Water TreatmentUS$ 0.3 - 25MOQ: 1 Piece
-
Ptfe Pleated Filter Cartridge for Coating-solventUS$ 0.3 - 25MOQ: 1 Piece
-
Ptfe Sterile Vent Filter Cartridge for Water TreatmentUS$ 0.3 - 25MOQ: 1 Piece
Material Of Construction |
Filter media |
Polypropylene |
|
Support Layers |
Polypropylene |
|
Micron rating |
0.1,0.2,0.45,0.65,1.0,2.0,3.0,5.0,10,30,50,70,100 μm |
|
Inner core |
Polypropylene |
|
Outer cage,End Cap |
Polypropylene |
|
Seal Method |
Thermal Bonded,No Adhesives |
|
O-ring/Gaskets |
EPDM,Slicone,Buna,Viton |
Cartridge Dimensions |
Outer Diameter |
69mm(2.75”) |
|
Inner Diameter |
28mm(1.10”) |
|
Length(Based on DOE End Cap) |
10”-254mm,20”-508mm,30”-762mm,40”-1016mm |
|
Filtration Area(m2) |
0.65m2 per 10” |
Operating Conditions |
Normal Operating Temperature |
Up to 65℃ (140℉) |
|
Max.Operating Temperature |
90℃ (194℉) at P≤1.0 bar (14.5psi) |
|
Forward Flow Direction |
4.2 bar (60 psi) at 25℃ (77℉) |
|
Reverse Flow Direction |
2.1 bar (30psi) at 25℃ (77℉). |
|
PH Value Compatibility |
1-14 |
|
Sterilization Temperature Time |
Steam Sterilization for 30 minutes at 121±2 ℃, 100 cycles, Autoclave 30minutes (optional)
|
Cartridge Safety |
Endotoxin |
<0.25 EU/ml |
|
Extractables |
0.03g / 10" |
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
