UF Membrane Module For Water Treatment/industrial UF Water Filter Equipment/ PVDF,PP,PAN Hollow Fiber Module

Model No.

HM200-1PAN

HM200-1PS

HM200-1PP

HM200-1PVDF

Size

L Φ200X1710mm   S Φ200X1450mm

L Φ200X1710mm   S Φ200X1450mm

L Φ200X1710mm   S Φ200X1450mm

L Φ200X1710mm    S Φ200X1450mm

Hollow fiber material

PAN

PS

PP

PVDF

Hollow fiber ID/OD

1.0mm / 1.6mm

1.0mm / 1.6mm

0.4mm / 0.5mm

0.7mm / 1.3mm

MWCO (Daltons)

50k~100k

10k~100k

50k~100k

100k~200k

Membrane area

L-34m²  S-27m²

L-34m²  S-27m²

L-56m²  S-48m²

L-47m²  S-40m²

Filtration method

Inside-out

Outside-in

Initial flux L/H, 0.1mpa, 25 ℃              pure water as feed

>9000 (L)     >6500 (S)

>9000 (L)     >6500 (S)

>9800 (L)    >7100 (S)

>9600 (L)    >7000 (S)

Designed water flux

40-120L/m²/h

40-80L/m²/h

End seal material

 Epoxy resins

Housing material

UPVC

Connection/Pipe

Coupling connection DN50 / PVC Pipe ID. 50mm

Max. Feed pressure

0.3mpa

0.3mpa

0.3mpa

0.25mpa

Max. trans-membrane pressure

0.2mpa

0.2mpa

0.2mpa

0.15mpa

Normal trans-membrane pressure

0.02-0.15mpa

0.02-0.15mpa

0.02-0.15mpa

0.01-0.1mpa

Feed turbidity

<50ntu

Permeate turbidity

<0.1ntu

Max. working temperature

5-45℃

PH range

3-9

2-12

1-14

2-13

Microorganism, pathogen

99.99% Removal
