SC-2169WP Wifi IP Phone
Suncomm WiFi IP Phone SC-2169WP is a highly innovative based wireless IP phone
for enterprise office use, integrated with 128x64 graphic LCD, a large resolution
display screen, elegant and intuitive user interface etc.
Application:
Key Features
128*64 Graphic LCD.
HD Voice: HD Codec, HD Speaker, HD Handset.
Multi-language: Chinese, English, French, Russian, etc.
2 level adjustable bracket and wall-mountable.
Two SIP accounts and support three-way conference, SMS.
1 x RJ45 port, 3.5mm and RJ-9Headset.
USB port for external unit charging.
Auto-provision, HTTP/TFTP/FTP , Tr069. XML/LDA, Contact Search.
Connect to the wifi network without cable.
Phone Feature:
2 SIP accounts, Hotline
Call hold, Call waiting, Call forward, Call return
Call transfer (blind/busy/ask)
Caller ID display, Redial, Mute, DND
Auto-answer, 3-way conferencing
Speed dial, SMS, Voicemail
Message Waiting Indication LED
Tone scheme, Volume control
Direct IP call without SIP proxy
Ring tone selection/import/delete
Phonebook (Personal Phone Book
Search/Input/Output (300 entries),
Black list, Hand-free indicator.
Call history: dialed/received/missed (100
-entries); One-key back (C)
Multi-Language (2aB/abc/ABC/123)
Soft keys programmable, Supports PC control
Support switching SIP server & Second server
Advanced Features
XML Phone Book search and input & output
Enterprise phone book(800 entries)
LDAP phone book
Functions customizable keys
IP PBX System Integration
Busy lamp field (BLF), BLF list
Bridged line appearance (BLA)
DND & Forward synchronization
Intercom, Paging, Music on hold
Call pickup, Dial Plan, Call recording
Anonymous call, Anonymous call rejection
Network conference, Distinctive ringtone
Security
802.1x, VLAN QoS (802.1pq)
Transport Layer Security (TLS)
Digest authentication using MD5/MD5-sess
Secure configuration file via AES encryption
Phone lock for personal privacy protection
Admin/VAR/User 3-level configuration mode
Network Features
SIP v1 (RFC2543), v2 (RFC3261)
SIP connection: Proxy mode & Peering Points mode
DNS SRV (RFC3263)
Redundant server support
NAT Traversal: STUN mode
DTMF: In-Band, RFC2833, SIP Info, Auto
HTTP/HTTPS Web Management
IP Assignment: Static/DHCP/PPPoE
Bridge/Router mode for PC port
TFTP/DHCP/PPPoE client
Telnet/HTTP/HTTPS server
DNS client, NAT/DHCP server
WIFI: 802.11b/g/n
Management
Auto-provision via FTP/TFTP/HTTP/HTTPS
SNMP V1/2 , TR069
Configuration: browser/phone/auto-provision
Trace package and system log export
Codes and Voice Features
Wideband Codec: G.722
Narrowband codec: G.711μ/A, G.723.1
G.726, G.729AB,VAD, CNG, AEC, AGC
Full-duplex,
Physical Features
128x64 graphic LCD
33 keys including 2 programmable keys
1x3.5mm handset port,1xRJ9 headset port
1xRJ45 10/100M Ethernet ports
2 level adjustable bracket and wall-mountable
Power adapter: AC 100~240V input and
DC 5V/1A output
Power consumption: 1.4-2.6W
Net weight: 0.80KG
Dimension: 185x200x90MM
Operating humidity: 10~95%
Storage temperature: up to 60°C
Package Features
Qty/CTN: 10 PCS
N.W/CTN:12.50 KGS; G.W/CTN: 13.50KGS
Measurement: 0.068CBM (0.5% more or less); Carton Meas: 500x480x320MM
|
