SC-08O 8FXO VoIP Gateway

SC-08O 8FXO VoIP Gateway thumbnail-1
SC-08O 8FXO VoIP Gateway thumbnail-2
SC-08O 8FXO VoIP Gateway thumbnail-3
SC-08O 8FXO VoIP Gateway thumbnail-4
SC-08O 8FXO VoIP Gateway photo-1
SC-08O 8FXO VoIP Gateway photo-2
SC-08O 8FXO VoIP Gateway photo-3
SC-08O 8FXO VoIP Gateway photo-4
US$ 1 - 50 MOQ: 1000 Units
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
OEM
Model Number:
SC-08O
Contact Supplier Request Quote Chat Now
Suncomm Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen / Taipei
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name OEM
Model Number SC-08O



Product Description

  SC-08O 8FXO VoIP Gateway



Key benefits



  • Primary and secondary SIP account

  • Flexible setup FXO port group

  • IP trunk

  • Flexible routing and manipulation

  • Data/Voice/Management VLAN

  • Voice and FAX all in one

  • SNMP

  • Firmware update automatically /configure update



    Protocol



  • SIP V2.0 (RFC 3261,3262,3264)

  • SDP (RFC 2327)

  • REFER (RFC 3515)

  • RTP/RTCP (RFC 1889,1890)

  • STUN (RFC 3489)

  • ARP/RARP (RFC 826/903)

  • SNTP (RFC 2030)

  • DHCP/PPPoE

  • TFTP/HTTP/HTTPS

  • DNS/DNS SRV (RFC 1706/RFC 2782)

  • VLAN 802.1P/802.1Q

  • Diff Serve



    Voice & Fax

  • G.711A/U law, G.723.1, G.729A/B

  • Comfort Noise Generation(CNG)

  • Voice Activity Detection(VAD)

  • Echo Cancellation(G.168)

  • Adaptive (Dynamic) Jitter Buffer

  • Programmable Gain Control

  • T.38/Pass-through/Modem FAX mode,

  • Up to 14.4kbps

  • DTMF mode: Signal/RFC2833/INBAND



    FXO Features

  • Busy tone detection

  • No current take out stitches

  • Detection Voice interrupted

  • Detection One stage dialing

  • Two stage dialing

  • PSTN exterior ports polling

  • Polarity Reversal

  • FAS( Fake billing correction )

  • DC/AC impedance config

  • Caller ID detection (Bellcore Type 1&2, ETSI,DTMF)



    Private Service

  • Inquire LAN port IP *158#

  • Inquire WAN port IP *159#

  • Get IP address *150*

  • Restart *111#

  • Factory reset *166*000000#



    Maintain & Upgrade

  • Web based configuration

  • Telnet configuration

  • Data backup/restore

  • Support English and Chinese language

  • Firmware upgrade by TFTP

  • Web & telnet login password modify

  • Factory reset

  • Automatic time synchronization

  • SNMP

  • IVR local maintenance management



    Network Features

  • NAT (Rout& Bridge)

  • Static IP, PPPoE, DHCP

  • DHCP server

  • MAC address clone

  • DMZ

  • IP,TCP, UDP,TFTP, FTP, TCP,ARP,RARP,

  • Ping, NTP, SNTP, Http, DNS, Tracert

  • Static/dynamic ARP



    Physical properties

  • Power: input:100-240V,50-60Hz,1.2A Max

  • 4FXO output: 12VDC,1A

  • 8FXO output:12VDC,2A

  • 16FXO optput:110-240VAC, 0.5A

  • power consumption(W): 4FXO:12;

  • 8FXO:20;16FXO:48

  • Temperature(operation): 0 ℃ ~ 45 ℃

  • (storage): -20 ℃ ~80 ℃

  • Operation Humidity: 10%-90%

  • no condensation

  • Dimension(w/D/H):

  • 4/8FXO 242*152*40mm 1kg

  • 16FXO 442*280*44mm 3.0kg



    Call & Routing

  • FXO port group

  • IP Trunk

  • Primary and secondary SIP account

  • 32 inbound routing

  • 32 outbound routing

  • Number manipulation

  • Dial plan set



    Authentication

    CE, FCC
