SC-9076-PE Promotion IP Phone with PoE with 2 SIP, LED for call and message waiting indication

Codec: G.722, G.711(A/μ), G.723.1, G.729AB, G.726, iLBC

DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO

Full-duplex hands-free speakerphone with AEC

Call hold, mute, DND

One-touch speed dial, hotline

Call forward, call waiting, call transfer

SMS

Redial, call return, auto answer

Local 3-way conferencing

Direct IP call without SIP proxy

Ring tone selection/import/delete

Set date time manually or automatically

Dial plan

Black list

XML/LDAP remote phonebook

Intelligent search method

Phonebook search/import/export

Hot-desking, emergency call

Message Waiting Indicator (MWI)

Voice mail

Call park, call pickup

Intercom, paging

Music on hold

Call completion

LED for call and message waiting indication

Intuitive user interface with soft keys

National language selection

AC 100~240V input and DC 5V/1A output

Power consumption (PSU): 1.3-2.1W

Power consumption (PoE): 1.8-3.1W

Dimension: 210 x 170 x 45mm

Operating humidity: 10~95%

3 “soft” keys

5 navigation keys

Volume control keys

2 x RJ45 10/100M Ethernet ports

Power over Ethernet (IEEE 802.3af), class 2

1 x RJ-9 (4P4C) handset port

Call server redundancy supported

NAT transverse: STUN mode

Proxy mode and peer-to-peer SIP link mode

IP assignment: static/DHCP/PPPoE

HTTP/HTTPS web server

Time and date synchronization using SNTP

UDP/TCP/DNS-SRV(RFC 3263)

QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP

SRTP for voice

Transport Layer Security (TLS)

HTTPS certificate manager

AES encryption for configuration file

Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy

Phone lock for personal privacy protection

Reset to factory, reboot

N.W/CTN: 9.3 KG

G.W/CTN: 10.3 KG

Gift box size: 230 X 290 X 55 mm
