Help CenterSC-608 4G LTE Router With VoIP and 1 WAN, 4 LAN, With B42 , B28 All 4G Bands, Indoor CPE
Related Products
-
150M 4G LTE FDD TDD WLAN Indoor CPE Wireless RouterUS$ 1 - 30MOQ: 100 Units -
SC-700 4G LTE Outdoor CPE , ODU , Band 42 , Band 28 Outdoor CPE Wireless RouterUS$ 1 - 30MOQ: 100 Units
-
SC-2296-4GW 4G LTE Indoor Router (Indoor CPE), Band 42US$ 1 - 10MOQ: 3000 Units
-
SC-2295-4GW 4G 4G LTE Wireless RouterUS$ 1 - 10MOQ: 3000 Units
-
SC-2296S-4GW Easier and Faster 4G LTE WIFI Router With 4G SIM Card Band 42US$ 1 - 10MOQ: 1000 Units
-
Basic Description
Spec. |
Description |
Comment |
LTE chip set |
SQN3120 + SQN3140 |
Sequans |
LTE Standard |
3GPP Release9 CAT4 |
|
Host |
AR9341 |
Qualcomm |
Flash |
16MB |
SPI NOR Flash |
DDR2 Memory |
64MB |
DDR2 SDRAM |
Ethernet LAN Port |
Four RJ-45 port 10/100 auto-sensing,auto-MDX |
Four LAN Port |
Voice POTS port |
Two FXS RJ-11 ports |
Optional Feature |
USB Port |
One USB 2.0 Type A |
|
LED Indicators |
Power/WiFi/Voice/Mode/Signal Strength/LAN Indicator |
|
USIM |
Support 1.8V/3.0V 2FF USIM |
|
Power Switch |
Power switch, mini rocker switch |
|
Reset/Reboot Button |
Tact switch |
Touch reset functions within 1s completed; long press over 10s to restore the factory settings |
WPS Button |
Tact switch |
|
WiFi Button |
Tact switch |
Control WiFi turn on or off |
Power Supply |
Input :Universal range 100~240V AC Output:12V/1.5A DC |
|
-
ID Design
Appearance Index
Index |
Description |
Dimension |
167(H)× 187(W)× 44(T)mm |
Weight |
About 310g |
Color |
White or other customization color |
Interface and Button
Connectors |
Description |
ETH RJ45 |
Four LAN |
POTS-RJ11 |
2 RJ11 interface, phone / fax / POS, providing VoIP functions under conditions of software support |
USB Type |
USB 2.0, can be switched to the LTE module directly |
USIM Slot |
Support 1.8V/3.0V USIM |
Power |
The Power port is where you connect the enclosed power adapter |
Reset/Reboot |
Touch reset functions within 1s completed; long press over 10s to restore the factory settings |
WPS |
Touch the WPS Button, WiFi successfully set |
WiFi |
Turn on or off WiFi Function |
Software Specification
WAN port packet forwarding capability:> 80Mbps
Spec |
Description |
Functions |
Support 802.11 b/g/n |
Support FAT AP | |
POTS interface supports fax and POS (optional) | |
| WAN port packet forwarding capability:> 80Mbps | |
|
Users can manually modify the USIM card PIN code; When the PIN verification, after the first manual check, follow-up support automatic verification; After the PIN code input reaches the maximum number of attempts, USIM card will be blocked, and support the PUK code to unlock function; | |
Support modify the APN manually by WEB UI | |
Multi APN support, up to 4 APNs support | |
WEB UI support OS: Windows XP above SP3, Window 7, Vista, Linux. | |
USB2.0 |
1. Direct access the module 2. Upgrade module firmware from USB2.0 port 3. IOT test should use this port |
WIFI Features |
1. Users can switch WLAN function through two ways, one is touch the WLAN button, the second is Web UI. 2. Support configuration WLAN functions through Web UI, include: SSID, SSID broadcasting turn on/off, AP Isolate function, Channel, rate and mode 3. Support encryption: Un-encrypted, WEP-OPEN, WEP-SHARED, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (TKIP), WPA2-PSK (AES) 4. Support WPS: Support PBC mode 5. WiFi protocol support: IEEE 802.11 b/g/n (2.401 – 2.483 GHz) |
Device Management |
Device management:Support TR069 1. Supports upload / download the ACS specified file; Support download CPE configuration file; 2. Support queries following parameters: PCI / RSRP / RSRQ / SINR / Transmit power / DL Packet Error Rate (PER) / MCS Data rate in downlink and uplink / MIMO mode in progress 3. Support configure the following parameters: Wan Configuration: Operation Mode, WAN Protocol, Get IP Method, WAN IP Address, WAN IP Subnet Mask, MTU; DHCP Server Configuration: DHCP Mode, Start IP, End IP, Lease Time, Relay IP; DMZ configuration: DMZ Host; VOIP-related parameters; 4. Support remote upgrade: Support batch or for individual CPE remote version upgrade and rollback operations; 5. Support CPE version update |
Router Functions |
1. Support Router mode and Bridge mode; 2. Users can automatically obtain IP parameters through static IP or dynamic mode (DNS) 3. Users can automatically obtain IP address through DHCP; 4. Supports user devices via a switch connected to the Internet by CPE LAN ports, maximum number of connections no less than 32; 5. Support via a router device connected to the Internet by CPE LAN ports. |
VPN |
Support VPN Pass-through |
Support L2TP/IPsec/PPTP | |
Support PPPoE |
Security
Feature |
Status |
Comments |
User Name/Password configuration |
Support |
|
Firewall Switch |
Support |
|
LAN MAC Filter |
Support |
|
IP Filter |
Support |
|
URL Filter |
Support |
|
|
L2/L3 Firewall -Basic firewall - Port Forwarding -uPnP -DMZ -Remote WAN Ping -Remote Web Access Control |
Support |
|
