6dB Power Tapper 698-2700 MHz N-femail Type

Name: 6dB Power Tapper 698-2700 MHz N-femail Type
Brand: setsail
SKU: 132988799

US$ 10.01 - 100 MOQ: 1 Piece

Key Specifications

Brand Name:

setsail

Model Number:

YFTX-PT-0727-06-NF

Hefei Setsail Telecom Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Brand Name setsail

Model Number YFTX-PT-0727-06-NF

Specifications

6dB power tapper 698-2700 MHz N-femail type
Manufacture for 9 years
Higy quality & best service
Fast delivery
OEM is OK

6dB power tapper 698-2700 MHz N-femail type

Applications:

1. Used in telecommunication application to split the one Input signal into two/three/four paths

2. Widely used in the Building coverage applications

3. Mobile Communication Network Optimization and In-door distribution system.

4. Cluster communication, satellite communication, shortwave communication and hopping radio.

5. Radar, electronic navigation and electronic confrontation.

6. Aerospace equipment systems

Technical Specifications:

Model	YF-PT-727 -5-DF	YF-PT-727 -6-DF	YF-PT-727 -7DF	YF-PT-727 -10DF	YF-PT-727 -15-DF	YF-PT-727 -20-DF	YF-PT-727 -30-DF	YF-PT-727 -40-DF
Coupling(dB)	5±0.8dB	6±1.0dB	7±1.0dB	10±1.2dB	15±1.3dB	20±1.3dB	30±1.5dB	40±2dB
Insertion Loss(dB)	2.0dB	1.7dB	1.35dB	0.85dB	0.5dB	0.4 dB	0.35 dB	0.30 dB
Frequency(MHz)	698-960/1710-2700MHz
Return Loss (dB)	≤-16dB
Power Capacity(W)	200Wmax
Impedance(ohm)	50
RF Connector	N-female
3^rd order IMD	<-150dBc
IP Grade	IP65
Temperature(deg)	-35°C ~ +75°C
Relative humidity	0 to 95%
Color	Black-plated or Silvery-white Plated
