2.4GHz 5w WIFI Signal Booster ( 1000mW wifi signal booster 5W Amplifier )
Product Description:
The 2.4 GHz WLAN signal booster is designed for IEEE 802.11b/g/n Wireless LAN applications. It adopts the direct sequence spread spectrum (DSSS) and orthogonal frequency division multiplexing (OFDM) technology of WLAN communication. The product is compatible with time division duplex (TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/WiFi devices and increase the WLAN signal strength, therefore a larger WLAN coverage and more stable transmission rate.
Product Features
1. 50X the power, improving the link quality and coverage of certified WLAN devices
2. Working with certified IEEE 802.11b/g/n Wireless LAN devices
3. Simply plug and play, no software is required
4.Equipped with LED to indicate wireless transmission and receiving
5.High quality RF connectors, RP-SMA
Technical & Merchanical Specifications
Frequency Range: 2.4~2.5GHz
Operating Voltage: 6~18V
Receiving Gain: 10dB±1
Transmission Gain: 17dB±1
Input Trigger PowerMin: 3dBm Max:20dBm
Maximum Output Power(P1dB): 37dBm( 5W )
EVM: 3%@29dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz
DC Supply Current: 625mA@Pout 29dBm 12V
Noise Figure: <3.0dB
TX/RX Switch Time Delay: < 1us
LED Indicator: Transmitter: green; Receiver: red
Operating Ambient Temperature: -40℃~+70℃
Operating Humidity: up to 95% rel. humidity
Factory
Exhibitions
FRQs
Question 1: Are you a manufacturer or a trading company?
Answer: ♣ We are a manufacturer of Passive Components for DAS since 2002.
Question 2: How can I get some samples?
Answer: ♣ We are honored to offer you samples for free, but the new clients are expected to pay the express charges and the charges will be deducted from the payment of future formal orders.
Question 3: Can your company do OEM business and put my logo onto the products?
Answer: ♣ Yes. We can do OEM business and put your logo onto the products. 80% of our oversea business is OEM.
Question 4: What is your MOQ of this product?
Answer: ♣ We do not have MOQ requirement for customers.
Question 5: What os your Delivery Time after advance payment is received?
Answer: ♣ 100-300pcs: 5-7 days
301-500pcs: 7-9 days
501-1000pcs: 10-13 days
