Help CenterDC-3G Fixed Coaxial Attenuator Microwave 20db RF
Related Products
-
DC-3G Fixed Coaxial 20db Attenuator Microwave RFUS$ 0.5 - 2MOQ: 50 Pieces -
DC-3G Coaxial Attenuator 20dbUS$ 0.5 - 2MOQ: 50 Pieces
-
DC-3G Fixed Coaxial 200W Attenuators 60db N-MaleUS$ 0.5 - 2MOQ: 50 Pieces
-
DC-3G Fixed Coaxial 200W Microwave Attenuators 60db N-MaleUS$ 1 - 2MOQ: 50 Pieces
-
DC-3G Fixed Coaxial 200W Attenuators in Microwave 60db N-MaleUS$ 8 - 10MOQ: 50 Pieces
Specifications
1.Manufacturer of Attenuator microwave 20db RF2.Power Rating:30W Attenuator
3.VSWR(max):1.2:1
4.Frequency Range:DC-3GHz
Fixed Attenuator
Attenuator is an electronic device which reduces signal power without appreciably distorting its waveform. Working in the opposite way of amplifiers which provide gain, attenuators actually kill gain.
Today, RF attenuators are widely applied in radio frequency signal conditioning and level control areas. They can be used to reduce the amplitude of an RF signal, match the impedances of sources and loads, and measure the gain or loss of a passive device made from voltage divider networks.
According to the technology they use, RF attenuators have three types: fixed attenuators, variable attenuators and switched attenuators.
30W DC-3GHz Directional Fixed Coaxial Attenuator mcrowave 20 db RF
Product Name |
30W 20dB RF Coaxial Attenuator microwave |
Model Number |
YF-RFCA-30W-N |
Operating Frequency( GHz ) |
DC-3.0 |
Impendence( Ohm ) |
50 |
VSWR |
≤1.20:1 |
Application |
Indoor |
Average Power ( W ) |
30 |
Attenuation( dB ) |
20 |
Tolerance( dB ) |
±0.8 |
Interface |
N (M) - N (F) |
Operating Temperature( °C ) |
-40 ~ + 80 |
Connector Material |
Brass |
Color |
Silver |
