Help CenterDC-3G, 5W, 10dB, RF Variable Attenuator
Related Products
-
DC-3G, 2W, 10dB, RF Variable Step AttenuatorNegotiableMOQ: 1 Piece -
DIN (7/16), 100W Coaxial RF AttenuatorUS$ 1 - 100MOQ: 1 Piece
-
7/16 DIN, RF 100W Attenuator 20dbUS$ 1 - 100MOQ: 1 Piece
-
DIN (7/16), 100W N 30dB AttenuatorUS$ 1 - 100MOQ: 1 Piece
-
DIN (7/16), 100 Watts N 3dB AttenuatorsUS$ 1 - 100MOQ: 3 Pieces
Specifications
1. We are Manufacturer2. OEM Service is available
3. 10pcs in stock
4. Best Price and Service
5. Warranty Time:3 Years
Applications: DC-3G, 5W, 10dB, RF Variable Attenuator
1. RF Step Variable Attenuator is widely used in below fileds:
A. Mobile Communication Network Optimization and In-door distribution system.
B. Cluster communication, satellite communication, shortwave communication and hopping radio.
C. Radar, electronic navigation and electronic confrontation.
D. Aerospace equipment systems.
2. RF Step Variable Attenuator is just one of SETSAIL's RF Attenuators Products Line. SETSAIL is capable of manufacturing and providing 1W, 2W, 5W, 10W, 15W, 20W, 25W, 30W, 50W, 100W, 200W, 300W, 500W RF Attenuator. The Frequency can reach DC-3G, DC-6G, DC-8G, DC-12.4G ,DC-18G, DC-26G, DC-40G. RF Connectors can be N-type, SMA-type, DIN-type, TNC-type and BNC-type.
Technical Specifications:
Main Specifications | |||||||
Part Number |
YF-VATT-3G-10-NF |
||||||
Operating Frequency( GHz ) |
DC-3.0 |
||||||
Impendence( Ohm ) |
50 |
||||||
VSWR |
≤1.50:1 |
||||||
Application |
Indoor |
||||||
Average Power ( W ) |
5 |
||||||
Attenuation( dB ) |
0-10dB in 1dB Step |
||||||
Tolerance( dB ) |
±1.5 |
||||||
Interface |
N (F) |
||||||
Operating Temperature( °C ) |
-40 ~ + 80 |
||||||
Dimensions( mm ) |
See Below Outline Drawing |
||||||
Connector Material |
Brass |
||||||
Related Products: 1-200W RF Fixed Coaxial Attenuators
200W RF Fixed Attenuators (3-60dB)
100W RF Coaxial Fixed Attenuator
50W RF Fixed Coaxial Attenuator (N-connector)
50W RF Fixed Coaxial Attenuator (7/16 DIN Connector)
30W/25W RF Fixed Coaxial Attenuator (N Connector)
10W/15W RF Fixed Coaxial Attenuator
1W/2W/5W RF Fixed Coaxial Attenuator (N Connector)
