Help Center200W RF Fixed Attenuator DC-3G N Male Connector
Related Products
-
DC-3G, 200W Fixed RF AttenuatorUS$ 1 - 100MOQ: 1 Piece -
DC-3GHz, 200W High Power Attenuator CoaxialUS$ 1 - 100MOQ: 1 Piece
-
DC-3GHz RF Fixed Attenuator 200W 30dBUS$ 1 - 100MOQ: 3 Pieces
-
DC-3GHz, 200W RF Attenuator ManufacturerUS$ 1 - 100MOQ: 3 Pieces
-
DC-3000MHz 200w rf Attenuator CoaxialUS$ 1 - 100MOQ: 3 Pieces
Applications: DC-3G, 200W Coaxial RF Attenuator (N connector)
1. 200W Coaxial RF Attenuator is widely exproted to Middle East , India, North American, Australia, South American, Southeast Asia. In 2009, Setsail has successfully exported more than 10,000 pcs to oversea customers. Products quality has been widely confirmed and accepted by oversea customers. The annual exporting quantity of the 200W RF Coaxial Attenuator is around 40,000pcs, especially to some big developping countries, like India, Paskitan, Brazil.
2. 200W Coaxial RF Attenuator is widely used in below fileds:
A. Mobile Communication Network Optimization and In-door distribution system.
B. Cluster communication, satellite communication, shortwave communication and hopping radio.
C. Radar, electronic navigation and electronic confrontation.
D. Aerospace equipment systems.
3. 200W Coaxial RF Atenuator is just one of SETSAIL's RF Attenuators Products Line. SETSAIL is capable of manufacturing and providing 1W, 2W, 5W, 10W, 15W, 20W, 25W, 30W, 50W, 100W, 200W, 300W, 500W RF Attenuator. The Frequency can reach DC-3G, DC-6G, DC-8G, DC-12.4G ,DC-18G, DC-26G, DC-40G. RF Connectors can be N-type, SMA-type, DIN-type, TNC-type and BNC-type.
Technical Specifications:
Main Specifications | |||||||
Part Number |
YF-ATT-3G-(3-60)-200W-NSF |
||||||
Operating Frequency( GHz ) |
DC-3.0 |
||||||
Impendence( Ohm ) |
50 |
||||||
VSWR |
≤1.20:1 |
||||||
Application |
Indoor or Outdoor |
||||||
Average Power ( W ) |
200 |
||||||
Attenuation( dB ) |
3-6 |
10 |
20 |
30 |
40 |
50 | 60 |
Tolerance( dB ) |
±0.5 |
±0.8 |
±1.0 |
±1.2 |
±2.0 |
±2.5 | ±3.0 |
Interface |
N (M) - N (F) |
||||||
Operating Temperature( °C ) |
-40 ~ + 80 |
||||||
Dimensions( mm ) |
See Below Outline Drawing |
||||||
Connector Material |
Brass |
||||||
