Swing arm cutting press for shoe sole
Features of swing arm cutting press for shoe sole
1.Can make big cutting area:1000*500mm or as required.
3.Hydraulic,automatic,material precision 0.01mm,no burned.
4.Die cutting machine force:120KN-150KN,Cut material by dies/moulds.
5.Die cutting disposable blister,leather,foam,EVA,sponge,plastic sheet ect.
6.Distance between the upper platen and the working table surface:60-150mm.
7.Suitable for material: such industries as plastics packing, pearl cotton packaging, rubber, such as EVA floor, PVC floor, asphalt floor, plastic floor, rubber floor and printing etc.
The parameters of swing arm cutting press for shoe sole:
Model number |
GSB-2C/12 |
GSB-2C/20 |
GSB-2C/25 |
Max scissor force |
120KN |
200KN |
250KN |
Sway arm width |
330×450mm |
350×550mm |
450×550mm |
Stroke adjustment |
5-55mm |
5-75mm |
5-75mm |
Seissor speed |
0.10m/s |
0.10m/s |
0.10m/s |
|
Distance between upper table and lower table |
60-140mm |
65-150mm |
|
Upper and lower tables |
900×410mm |
1000×500mm |
|
Motor power |
0.75KW |
1.5KW |
|
1.Equipped with lubricating system to lessen wear and prolong service life.
2.People can adjust height of sway arm from table by simple handle, convenient, stable.
3.Safe, two-hand trip operation; the sway arm can swing freely. Best operation line of sight.
4.The central oil supply automatic lubricating systrem gurantees the service life and precision of machine.
5.Lower limit of stroke is controlled by a time-lapse circuit with high precision, so it can make high-quality shoes.
6.Used to cutting plastic boards, leather, fiber, cotton fiber, paper cartons and other similar materials; especially suitable for shoe industry.
Our company has been a leading die cutting machine manufacturer for more than 20 years.These industries include paper, gaskets, foam , rubber, packaging, abrasives, plastics, auto interior components, composites, industrial textiles, footwear, leather, wood, floor etc.
"Jiayu" brand machinery has been formed cutting, pressing, sheet cutting, system bang, bang on flat, hot stamping, composite, packaging, assembly line, die (a) ten series sixty varieties. Main products of "Jia yu" brand are 10-25T hydraulic swing arm type cutting machine, 25-50T hydraulic gantry mobile cutting machine, 25-35T hydraulic plane type cutting machine, 30-300T precise four-column automatic balance type single bilateral feed cutting machine, 25-300T hydraulic four pillar type cutting machine, 30-50T precise four-column translation type hydraulic cutting machine, gantry type automatic feed continuous cutting hydraulic cutting machine, etc, they can be widely used in shoes, bags, leather goods, clothing, gauze, cap industry, timber, toys, automotive interior, packaging, stationery, blister, polyamine ester processing etc, the products favored by domestic and foreign merchants' favor.
1)Q:What's your after-sales service?
A:Engineer available to serve machines over seas;Email and calling service in working hour; 24 hours door to door in domestic.
2)Q:Are you a factory or trading company?
A:We are a factory and manufacturer.
3)Q:What's warranty of swing arm cutting press for shoe sole ?
