Help CenterDC-3G RF Attenuator 100W 60dB
Related Products
-
DC-3G, RF High Power Attenuator 100WNegotiableMOQ: 5 Pieces -
RF Attenuators Coaxial, 3G, 100W, 3-60dBNegotiableMOQ: 5 Pieces
-
RF Coaxial 100W Attenuator (DC-3000MHz, N Connector)NegotiableMOQ: 5 Pieces
-
DC-3000MHz, 100W RF Coaxial Attenuator WifiNegotiableMOQ: 3 Pieces
-
DC-3000MHz, RF Coaxial 10dB Attenuator (100W)NegotiableMOQ: 3 Pieces
Applications: Coaxial Fixed 100W RF Attenuator (DC-3G, N-connector)
1. 100W RF Attenuator is widely exproted to Middle East , India, North American, Australia, South American, Southeast Asia. In 2008, Setsail has successfully exported more than 10,000 pcs to one of Brazil customers, which is used in ZTE's IBS and BTS projects in Brazil. Products quality has been confirmed and accepted by oversea customers. The annual exporting quantity of the Coaxial Fixed 100W RF Attenuator is around 50,000pcs, especially to some big developping countries, like India, Paskitan, Brazil.
2. Fixed 100W RF Attenuator is widely used in below fileds:
A. Mobile Communication Network Optimization and In-door distribution system.
B. Cluster communication, satellite communication, shortwave communication and hopping radio.
C. Radar, electronic navigation and electronic confrontation.
D. Aerospace equipment systems.
3. Coaxial Fixed 100W RF Attenuator is just one of SETSAIL's RF Attenuators Products Line. SETSAIL is capable of manufacturing and providing 1W, 2W, 5W, 10W, 15W, 20W, 25W, 30W, 50W, 100W, 200W, 300W, 500W RF Attenuator. The Frequency can reach DC-3G, DC-6G, DC-8G, DC-12.4G ,DC-18G, DC-26G, DC-40G. RF Connectors can be N-type, SMA-type, DIN-type, TNC-type and BNC-type.
Technical Specifications:
Main Specifications | |||||||
Part Number |
YF-ATT-3G-(3-40)-100W-NSF |
||||||
Operating Frequency( GHz ) |
DC-3.0 |
||||||
Impendence( Ohm ) |
50 |
||||||
VSWR |
≤1.20:1 |
||||||
Application |
Indoor or Outdoor |
||||||
Average Power ( W ) |
100 |
||||||
Attenuation( dB ) |
3-6 |
10 |
20 |
30 |
40 |
50 | 60 |
Tolerance( dB ) |
±0.5 |
±0.8 |
±1.0 |
±1.2 |
±2.0 |
±2.5 | ±3.0 |
Interface |
N (M) - N (F) |
||||||
Operating Temperature( °C ) |
-40 ~ + 80 |
||||||
Dimensions( mm ) |
See Below Outline Drawing |
||||||
Connector Material |
Brass |
||||||
