Specifications
1) Manufacturer of power divider2) Low insertion loss and high isolation
3) Micro-strip power dividers
Power dividers are used in a wide variety of applications and can satisfy almost any requirement where a signal needs to be distributed or combined. SETSAIL’s compact, microstrip divider/combiners provide minimal insertion loss while delivering high isolation between output ports with exceptional phase and amplitude balance.
4-way micro-strip SMA-F Power Dividers/splitters
Product Name |
4-way micro-strip SMA-F Power Divider/splitter |
||
Model |
YFTX-MPS-0825-02NF |
YFTX-MPS-0825-03NF |
YFTX-MPS-0825-04NF |
Frequency(MHz) |
800-2500MHz/800-2700MHz/698-2700MHz /350-520MHz /350-1000MHz |
||
Insertion Loss(dB) |
<=3.4 |
<=5.5 |
<=6.5 |
Isolation(dB) |
>=20 |
||
VSWR |
<=1.30:1 |
||
Power Capacity(W) |
50 |
||
Impedance(ohm) |
50 |
||
RF Connector |
SMA-female |
||
Application |
Indoor |
||
Operating Temperature(deg) |
-35~+60 |
||
Color |
Black-plated |
||
Relative Humidity |
5%-95% |
||
Power splitter/dividers Applications:
1.Mobile Communication Network Optimization and In-door distribution system
2.Cluster Communication, Satellite Communication, Shortwave Communication and Hopping Radio
3. Radar, Electronic Navigation and Electronic Confrontation
4. Aerospace Equipment systems
