Help CenterN Type rf Power Splitter 4 Way (0.8-2.5GHz)
Related Products
-
N-Female 3-way Power Splitter/divider(0.8-2.5GHz)NegotiableMOQ: 50 Pieces -
N-Female 4-way Cavity Power Splitter/divider(0.8-2.5GHz)NegotiableMOQ: 50 Pieces
-
700-2400MHz, SMA, 4 Way RF Power Splitter/DividerNegotiableMOQ: 1 Piece
-
700-2400MHz, SMA, 4 Way Power SplitterUS$ 1 - 50MOQ: 3 Pieces
-
700-2400MHz, SMA, 4 Way RF SplitterUS$ 1 - 50MOQ: 1 Piece
Application:
1. Used in telecommunication application to split the one Input signal into two paths.
2. Widely used in In-building coverage applications.
N-Female (0.8-2.5GHz ) power splitter 4 way
Product Name |
2-way Power Splitter/Dividers |
3-way Power Splitter/Dividers |
4-way Power Splitter/Dividers |
|
Model |
YFTX-CPS-0825-02NF-R |
YFTX-CPS-0825-03NF-R |
YFTX-CPS-0825-04NF-R |
|
Frequency(MHz) |
0.8-2.5GHz |
|||
Insertion Loss(dB) |
<=3.3 |
<=5.2 |
<=6.5 |
|
VSWR |
<=1.25:1 |
|||
PIM3 |
<=-120dBc/<=-140dBc/<=-150dBc<=-160dBc @2×43dBm |
|||
Power Capacity(W) |
300 |
|||
Impedance(ohm) |
50 |
|||
RF Connector |
N-female |
|||
Operating Temperature(deg) |
-35~+60 |
|||
Color |
Black-plated |
|||
Relative Humidity |
5%-95% |
|||
Water Proof |
IP60 or IP65 |
|||
Send Inquiry to This Supplier
