Help Center800-2700MHz, 2,3,4 Way RF Power Divider With Mounting Bracket
Related Products
-
3 Ways Low Power Splitter/Divider(800-2700MHz, Micro-strip)NegotiableMOQ: 1 Piece -
RF 4 Ways Low Power Divider/Splitter(800-2700MHz)NegotiableMOQ: 10 Pieces
-
0.7-2.7G, RF 2 Ways Low Power Splitter (Micro-strip)NegotiableMOQ: 1 Piece
-
RF Microwave 800-2500/800-2700/700-2700MHz Micro-strip Power Splitter/DividerNegotiableMOQ: 50 Pieces
-
2-way Multiband Power Splitter With Wall Mounting Bracket, 200W, N-femaleUS$ 1 - 50MOQ: 5 Pieces
Specifications
1. We are Manufacturer of RF Power Splitter2. OEM Service is available
3. 1000pcs in stock
4. Power Splitter with Best Price
Applications: 800-2700MHz, Square-type, 2,3,4 way, N-female, RF Reactive Power Splitter for IBS use
1. RF Power Splitter/Divider is widely exproted to Middle East , India, North American, Australia, South American, Southeast Asia. Power Divider is widely used in the IBS and BTS projects. All over the world, SETSAIL has sold most of the Power Splitter/Divider to ZTE and Huawei's oversea IBS and BTS contruction, especiall in Middle East and South American. Products quality has been confirmed and accepted by oversea customers. The annual exporting quantity of this 800-2700MHz, 2-way Power Splitter/Divider is around 50,000pcs, especially to some big developping countries, like India, Paskitan, Brazil.
2. 800-2700MHz(700-2700MHz), RF IBS Power Splitter/Divider is widely used in below fileds:
A. Mobile Communication Network Optimization and In-door distribution system.
B. Cluster communication, satellite communication, shortwave communication and hopping radio.
C. Radar, electronic navigation and electronic confrontation.
D. Aerospace equipment systems.
3. 800-2700MHz(700-2700MHz), RF IBS Power Splitter/Divider is just one of SETSAIL's RF Coupler Products Line. SETSAIL is capable of manufacturing and providing 800-2500MHz, 800-2700MHz, 700-2700MHz, 670-2700MHz, 350-2700MHz, 800-3000MHz, 350-520MHz, 350-1000MHz, 180-185MHz, 700-3500MHz RF Power Splitters. The connectors can be N-type, DIN-type, BNC-type, TNC-type and so on.
Technical Specifications:
800-2700MHz, Square-type, 2,3,4 way, N-female, RF Reactive Power Splitter for IBS use
With Mounting Brackets
Model |
YF-PS-0827-02-N-S-Z |
YF-PS-0827-03-N-S-Z |
YF-PS-0827-04-N-S-Z |
||
Frequency(MHz) |
800-2700 |
||||
Insertion loss(dB) |
3.3 |
5.4 |
6.5 |
||
| Color | Black-plated |
||||
VSWR |
1.25:1 |
||||
Power Capacity (W) |
200 |
||||
3rd order PIM |
-140dBc@2×43dBm |
||||
Impedance(ohm) |
50 |
||||
Temperature(deg) |
-35 deg to +60 deg |
||||
RF connector |
N-female |
||||
Relative Humidity |
5%-95% |
||||
Size(mm) |
2210.1×60.4×20 |
223.4×60.4×18 |
223.4×60.4×18 |
||
Wight(kg) |
0.20 |
0.30 |
0.40 |
||
Note: Specifications can be changed according with customers' requirements.
