Great Wall Small Scale Jaw Crusher in China
- 100 Unit / Units per Month
- Qingdao Shanghai Tianjin
- T/T Credit Card
You May Like
Product Details
Condition | New | Type | Other, Small Crusher | |
Application | Mining | Motor Type | AC Motor | |
Power(W) | Please refer to the specification | Capacity(t/h) | 1-100 | |
Place of Origin | Henan, China | Brand Name | Great Wall | |
Model Number | PE/PC Mini Crusher | Dimension(L*W*H) | Please refer to the specification | |
Weight | Please refer to the specification | Certification | ISO9001:2008 | |
Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Great Wall Small Scale Jaw Crusher in China1.High capacity.
2.Easy operation.
3.Simple structures.
4.Low investment cost.
"Great Wall Make Great Machine"
Different Colors&Packages are available
Other HOTEST MODELS For View
ISO9001:2008 Approved,For test report details,pls contact "GreatWall"
Mini Stone Crusher,Mini Crusher,Quarry Crusher Machine
Mini Crusher Machine Usage and Application
The Mini Stone Crusher is one of the most popular stone crushing equipments in the world. It is ideally suitable for primary and secondary crushing all kinds of minerals and rocks with comprehensive strength less than 320 MPa, and is widely used in industry of mining, building materials, road construction, railway and bridge infrastructure, hydroelectricity, chemical industry, Metallurgy, etc.
Mini Crusher Machine Features
1. Deep crushing chamber and no dead space, which greatly improves the feeding capacity and productivity;
2. High crushing ratio and even output granularity;
3. Adjustment device of gasket type discharging opening is reliable and convenient to use. The discharging opening has wide adjusting range. This can increase the flexibility of our equipment.
4. Lubrication system is safe and reliable. Accessories are convenient to replace, and little maintenance is needed.
5. Our jaw crusher has simple structure, reliable performance and low operating cost.
6. Our jaw crusher is a kind of energy saving equipment. Single machine can save 15% ~ 30% energy and whole system saves more than doubled energy.
7. Discharging opening has large adjusting range, so your different requirements can be satisfied.
8. Low noise and little dust.
Mini Crusher Machine Main Specifications
Model | Feed Opening Size | Max. Feeding Size | Adjustable Range of Output Size | Capacity | Motor Power | Weight | Overall |
PE250×400 | 250×400 | 200 | 20-50 | 5-20 | 15 | 2.9 | 1430×1310×1340 |
PE400×600 | 400×600 | 350 | 40-100 | 15-60 | 30-37 | 6.8 | 1700×1732×1653 |
PE500×750 | 500×750 | 425 | 50-100 | 40-100 | 45-55 | 11.2 | 2035×1921×2000 |
PE600×900 | 600×900 | 480 | 65-160 | 60-140 | 55-75 | 16.5 | 2290×2206×2370 |
PE750×1060 | 750×1060 | 630 | 80-150 | 80-230 | 90-110 | 29 | 2655×2302×3110 |
PE900×1200 | 900×1200 | 750 | 95-165 | 140-320 | 110-132 | 54.5 | 3789×3050×3025 |
PE1000×1200 | 1000×1200 | 850 | 105-185 | 180-400 | 160-200 | 56.5 | 3900×3320×3280 |
PE1200×1500 | 1200×1500 | 1020 | 150-300 | 250-650 | 220-250 | 99.6 | 4300×3540×4043 |
PEX150×250 | 150×250 | 125 | 10-40 | 1-3 | 5.5 | 0.85 | 896×745×935 |
PEX150×750 | 150×750 | 125 | 12-45 | 5-16 | 15 | 3.8 | 1205×1495×1203 |
PEX250×750 | 250×750 | 210 | 25-60 | 10-40 | 22-30 | 5 | 1667×1545×1020 |
PEX250×1000 | 250×1000 | 210 | 25-60 | 15-50 | 30-37 | 6.8 | 1964×1550×1380 |
PEX250×1200 | 250×1200 | 210 | 25-60 | 20-60 | 37-45 | 8.5 | 2192×1605×1415 |
PEX400×1200 | 400×1200 | 320 | 35-95 | 28-95 | 45-55 | 11.7 | 2256×2100×1960 |
Mini Hammer Crusher
Model | Max. Feeding | Output | Capacity | Motor Power | Weight |
PC400×300 | 100 | <15 | 3-10 | 11 | 0.86 |
PC600×400 | 120 | <15 | 8-15 | 22 | 1.55 |
PC800×600 | 150 | <20 | 10-40 | 55 | 4.8 |
PC1000×800 | 200 | <30 | 16-65 | 110 | 8.1 |
PC1300×1200 | 280 | <40 | 50-200 | 240 | 14.8 |
PC1600×1600 | 350 | <50 | 100-350 | 480 | 37.5 |
Services:
1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing the most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Small Scale Jaw Crusher.
