CDMA&GSM&DCS&3G/WLAN 3-band Combiners/triplexer

Name: CDMA&GSM&DCS&3G/WLAN 3-band Combiners/triplexer
Brand: SETSAIL
SKU: 132977035

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

SETSAIL

Model Number:

YFTX-RFCOM-05N

Hefei Setsail Telecom Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name SETSAIL

Model Number YFTX-RFCOM-05N

Specifications

CDMA&GSM&DCS&3G/WLAN three-band Combiners/triplexer
Low RF insertion loss and VSWR
High power handing ,High rejection

GSM/TD-SCMA(A&B&C)/WLAN Three Band Combiner /Triplexer

Technical Specifications:

Product Name	GSM/TD-SCMA(A&B&C)/WLAN Three Band Combiner s/Triplexer
Model	YFTX-RFCOM-TR-10N
Model	CH1:GSM	CH2:TD(A&B&C)	CH3:WLAN
Frequency(MHz)	885-954	1880-1920&2010-2025& 2320-2370MHz	2010-2025
Insertion Loss(dB)	≤0.6dB	<=0.6dB@ 2010-2025MHz <=0.9dB@2320-2370MHz	<=0.9dB
Passband Ripple(dB)	≤0.4dB	<=0.6dB@ 2010-2025MHz <=0.9dB@2320-2370MHz	<=0.6dB
Outband Rejection(dB)	≥80@CH2&3	>=80@CH1&3	>=80@CH1&2
VSWR	≤1.25
IM3	<=-120dBC@2×43dBm
Impedance(ohm)	50
Power(W)	200
Operating Temperature(deg)	-30~+65°C
Connector Type	N-K
Dimensions(mm)	20917640 (Without Connectors)
