Class b Power Supply Surge Protector

FOB Price

US$ 35 - 65 / Piece

50 Pieces(Min. Order)

Port Ningbo/Shanghai
Payment TermsT/T L/C D/P D/A Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	LEEYEE
Model Number	LY1-B60

Product Description

Specifications

class b power supply surge protector
1.Un:220V,380V
2.Pole:1~4p,In100ka
3.Bgrade lightning proof
4.IEC61643-1,GB18802.1

Class B power supply surge protector

Product Description:

LY1-(B)6 series surge protector/surge protective device spd is suitable for TN-S,TN-C-S,TT,IT etc power supply system of AC 50/60Hz, 380V and below, used at the equipptential connection, which protects the electric network not shocked by the thunder and lightning, it's design is according to GB18802.1, IEC61643-1.

Product Features

1,Could be replaced for the module not need rower cut.
2,Maximum current of endure the lightning stroke 50kA(10/350μs).
3,Time of response<100ns.
4,The color of visible window shows operating status,green means normal,red means abnormal.

Surge protector device, surge protector, class b power supply surge protector,surge protective device

Main technical parameters:

Techinical parameters	LY1-B200	LY1-B150	LY1-B120	LY1-B100	LU1-B80	LY1-B60
Rated operating voltage Un(V~)	220V 380V
Maximum continuous operating voltage Uc	385V/420V
Voltage protection level up(V~) KV	≤4.0	≤3.2	≤3.0	≤2.8	≤2.4	≤2.5
Maximum discharge current Imax(8/20μs)KA	150	150	120	100	80	60
Nominal discharge current In(8/20μs)KA	200	100	80	60	40	30
Response times	<25
The cross section of L/N line	25,35	16,25	16,25	16,25	16,25	16,25
The cross section of PE line	35	25,35	25,35	25,35	25,35	16,25
Fuse or switch(A)	63A,125A	63A	63A	63A	63A	63A,32A
The line section of communication and alarm	≤1.5
Operating environment °C	‘-40°C~85°C
Relative humidity 25°C	≤95%
Installation	Standard rail 35mm
Material of outer covering	Fiber glass reinforced plastic
