Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 5000-7000 pieces/day | Place of Origin | Shandong, China | |
| Brand Name | DONGYUE BRAND | Model Number | QT4-15C | |
| Voltage | 220V/240V/380V/415V | Power | 19.3kw | |
| Dimension(L*W*H) | 4000*1800*2800 | Certification | CE,SGS,ISO,BV | |
| Warranty | 12 month | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Germany technology made in ChinaFull auotmatic line
High efficiency
CE,SGS,ISO,BV
SIEMENSor ABB motor ,SCHNEIDER switch
qt4-15c large concrete pavers qt4-15 dongyue machinery group
1.Techinical Parameter of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
Dimension of host machine | 3500×2220×2850mm | Host machine power | 45.38KW |
Moulding area | 1025×810mm | Vibration force | 100KN |
Moulding period | 15-25S | Mixer model | JS750 |
The size of the pallet | 1350×900×30mm | General water Consumption | 12T/every day |
Weight of the host machine | 14T | ||
Voltage | Adapt to your local voltage | ||
2. production Capacity of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
Size(LxWxH) | Pcs/Mould | Pcs/ Hr | Pcs/ 8 Hr |
400X100X200 | 20 | 3000-3600 | 24000-28800 |
400X150X200 | 14 | 2100-2520 | 16800-20160 |
400X200X200 | 10 | 1500-1800 | 12000-14400 |
400X250X200 | 8 | 1200 | 9600 |
Paver:200X100X60 | 35 | 5250 | 42000 |
Paver:200X165X60 | 20 | 3000 | 24000 |
3.Material proportion of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
1. 8-10% cement, 30-40 % sand , 50-60% crushed stone.
2. 8-10% cement, 30% flyash, 60% sand or stone powder
4. Block catalogue of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
5.Mchine photo of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
6.Certificates of qt4-15c large concrete pavers qt4-15 dongyue machinery group :
7. company views:
qt4-15c large concrete pavers
....
