Diesel Forklift for Block Making Machine DONGYUE

Diesel Forklift for Block Making Machine DONGYUE thumbnail-1
Diesel Forklift for Block Making Machine DONGYUE photo-1
US$ 10,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
DONGYUE
Contact Supplier Request Quote Chat Now
Dongyue Machinery Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name DONGYUE
Model Number CPU
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 1000kg~100000kg
Max. Lifting Height 2500mm~6000mm
Min. Lifting Height 140MM
Fork Length 920mm~2420mm
Fork Width 120mm
Overall Dimensions 1860mm~4258mm
Certification iso9001/ce

Specifications

1.Diesel Forklift
2.Rated capacity(ton):1.5~10
3.Max height(m):2.5~6.5
4.Made in Chinese cost,German standard
5.ISO9001

Diesel Forklift Intorudce



1.Diesel Forklift Characteristics
    Integrated central control box the reliability of electric system
    Ergonomical design ensures best operation
    Energy-saving hydraulic system decreases fuel consumption
    High-quality hydraulic hoses, no oil leakage
    Wide-view mast design improves the productivity and safety

Diesel Forklift for Block Making Machine DONGYUE

2.Diesel Forklift Main Technical Parameters

Name

2 Ton Diesel Forklift

1.General

Model

 CPC(D)20

Power Type

Diesel

Rated capacity

kg

2000

Load center

mm

500

2.Dimension

Lift height                      H

mm

3000

Free Lift height                H4

mm

140

Fork size                LXWXH

mm

1070x102x40

Front overhang                 X

mm

484

Overall dimension

Length to fork face    L1

mm

2510

Overall width         B1

mm

1150

Mast lowered height   H1

mm

2050

Mast extended height  H3

mm

4040

Overhead guard height H2

mm

2060

Turning radius                   R

mm

2170

3.Performance

Travel speed(no load/full load)

Hydraulic

km/h

17/19

Mechanical

Shift I

8.5/9

Shift II

18.5/19

Lift speed with load

mm/sec

470

Max grade ability Max. grade ability

%

20

Service weight

kg

3550

4.Chassis

Tyre

Front



7.00-12-12PR

Rear



6.00-9-10PR

Tread

Front             B2

mm

970

Rear              B3

mm

970

Wheelbase                    Y

mm

1650

Ground clearance(full load/no load)

Mast           M

mm

85/105

Frame           F

115/120

5.Engine

Type

Diesel

Model

Chinese Xinchang C490

(KW/RPM)

Rated output

37/2650

(N.m/rpm)

Rated torque

148/1900



No. Of cylinder

4



Bore*stroke (mm)

90*100



Displacement(L)

2.54
