Argon inverter welder Mini Mig Welding MIG-105/135/150/175/195
- 100000 Set / Sets per Month
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
Aluminium CO2 Mig Welding MIG-105/135/150/175/195
-
Popular Mini Mig Welding MIG-105/135/150/175/195
-
High Frequency AC/DC TIG Inverter Welding Machine WSE-200 For Sale
-
AC/DC Aluminum TIG200 Welding Machine
-
Factory Price AC/DC TIG Inverter Welding Machine(WSE series)
-
2013 hot selling portable dc ac inverter tig welder
Product Details
Condition | New | Place of Origin | Zhejiang, China | |
Brand Name | ANDELI Or OEM | Model Number | MIG-105/135/150/175/195 | |
Wire Feeding Speed | N/A | Dimensions | 400*270*490mm | |
Weight | 16.5KG | Usage | welding different types of materials such as steel | |
Voltage | 230V | Power(W) | 3KVA-7.5KVA | |
Certification | ISO9001:2008,CE | Warranty | 1~2 Years | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Argon inverter mig welding machine1,CO2 MIG welder
2,single phase DC
3,portable,4,fan-cooled
inverer MIG welding welder
Features:
Single-phase,portable,fan-cooled wire welding machine for MIG/MAG(gas) welding.
With thermal protection complete with MIG welding accessories.
The kit for welding different types of materials such as steel, stainless steel.
Steel and aluminum is avaiable on request.
Item | MIG-105 | MIG-135 | MIG-150 | MIG-175 | MIG-195 |
Input Voltage(V) | 230 | 230 | 230 | 230 | 230 |
No-load Voltage(V) | 21-36 | 21-36 | 23-38 | 23-38 | 23-38 |
Current Arrange(A) | 35-90 | 40-120 | 40-140 | 40-160 | 40-180 |
Rated Duty Cycle(%) | 90A@10% 50A@35% | 120A@10% 65A@35% | 140A@10% 75A@35% | 160A@10% 120A@20% | 180A@10% 100A@35% |
input capacity(KVA) | 3 | 4.7 | 5.2 | 6.3 | 7.5 |
Class of insulation | H | H | H | H | H |
Applied welding Rod(MM) | 06-0.8 | 0.6-1.0 | 0.6-1.0 | 0.6-1.2 | 0.6-1.2 |
Fusa(A) | 13 | 13 | 16 | 16 | 20 |
net Weight(KG) | 16 | 16 | 16 | 16.5 | 16.5 |
Weight(KG) | 20 | 20 | 20 | 21 | 21 |
Dimension(CM) | 49*27*40 | 49*27*40 | 49*27*40 | 49*27*40 | 49*27*40 |
Packaging Dimension | 52*31*43 | 52*31*43 | 52*31*43 | 52*31*43 | 52*31*43 |
More Info:
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY ANDELI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device.
EVERY DAY WE ARE ON LINE,WELCOME TO CONTACT WITH US!!
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
