Specifications
mig welder1)Soft-switch inverter system
2)Full digital control (MCU+DSP)
3)Synergic operation, Double Pulse MIG/MAG
Professinal Sale Automatic Inverter CO2 MIG Welder MIG-500 Welding Machine Good Price
| Why choose us? |
1. 20 years - Andeli Group Co.,Ltd is founded in 1993. |
Professional MIG/MAG Multi-process Welding Machine: MIG-350 /500
Features:
1) Process: CO2/MAG/Pulse MIG/Pulse-on-Pulse MIG+DC Pulse TIG.
2) Soft Switch technology design.
3) Completely digitalized control system, friendly operation interface.
4) Synergic operation in MIG/MAG and Pulse MIG/MAG welding process.
5) Perfect starting arc & reducing melting ball on stopping arc.
6) Embedded welding expert database, Flexible parameters adjustment.
7) Capable for storing 100 sets of user-defined parameters.
8) Self-diagnostic and Self-protection functions.
9) Perfect air-cooling system, Intelligent Ventilator Management.
10) Full-digital control systems for wire feeder(optional).
11) The value of welding current / voltage and job mode could be adjusted by digital
torch (Optional, digital kits on wire feeder accordingly).
12) Advanced digital communication interfaces for automatic welding.
13) Remote software upgrading function available....
| Item No | MIG-350 | MIG-500 |
| Input Voltage | 3PH~,380/400V,50/60Hz | 3PH~,380/400V,50/60Hz |
| Rated Input Capacity | 18KVA | 32KVA |
| Rated Input Current | 21A | 37A |
| No-load Voltage | 58V | 70V |
| Rated Voltage Range | 31.5V | 39V |
| Output Current Range | 30-350A | 30-500A |
| Output Voltage Range | 15-40V | 15-50V |
| Rated Duty Cycle | 60% @ 350A | 60% @ 500A |
| Wire Spool Capacity | 300mm(15kg) | 300mm(15kg) |
| Wire Diameters | 0.8-1.6mm | 0.8-1.6mm |
| Torch Cooling Style | Water-cooled/Gas-cooled | Water-cooled/Gas-cooled |
| Dimension(LxWxH) | 800X450X1294mm | 800X450X1294mm |
| Weight | 65KG | 75KG |
Competive:
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY ANDELI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device.And we do producing many other different series too,if you feel interests,please send us an inquiry!
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
