AI-704M Four Loop Temperature Controller

AI-704M Four Loop Temperature Controller thumbnail-1
AI-704M Four Loop Temperature Controller thumbnail-2
AI-704M Four Loop Temperature Controller thumbnail-3
AI-704M Four Loop Temperature Controller thumbnail-4
AI-704M Four Loop Temperature Controller thumbnail-5
AI-704M Four Loop Temperature Controller photo-1
AI-704M Four Loop Temperature Controller photo-2
AI-704M Four Loop Temperature Controller photo-3
AI-704M Four Loop Temperature Controller photo-4
AI-704M Four Loop Temperature Controller photo-5
US$ 10 - 100 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Yudian
Model Number:
AI-704M AI-704M 4-Channel Digital Temperature controller
Contact Supplier Request Quote Chat Now
Xiamen Yudian Automation Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Yudian
Model Number AI-704M AI-704M 4-Channel Digital Temperature controller
Usage Industrial
Theory Other, Temperature Controller, four loop Temperature controller
Accuracy 0.2, ±0.2%FS±1digit
Temperature Range 0-9999

AI-704M four loop Temperature controller







AI-704M four loop Temperature controllerAI-704M four loop Temperature controller



AI-704M four loop Temperature controller

AI-704M FOUR loop Digital Temperature Pressure Water Gas Level Indicator 4-Channel Digital Temperature controller



Ideal for accurate signal and data collect of temperature, pressure, flow, level, humidity etc







1.Main feature



  • High measurement accuracy: 0.2%FS ± 0.1°C
  • Universal programmable module input
  • Universal input power- 85-264VAC, or 11-26VAC/VDC
  • Highly versatile Output, multiple modules available
  • Independent input specification per channel.
  • Support up to 2 isolated retransmission output.
  • Manual/auto pilot display.
  • CE, RoHS, ISO9001 approved



2. Technical specification



Control mode

On-off control mode
AI PID Control with Auto Tuning(AT)

Measurement accuracy

0.2%FS ± 1digit, 0.3%FS± 1digit(only for Cu50)

Resolution

0.01°C

Response time

≤0.3s ( when digital filter parameter dL=0)

Input

Thermocouple(with J1 module): K, S, R, T, E, J, N, WRe5~WRe26

Two-wire RTDs(with J2 module): Pt100, Cu50,0~80ohm,0~400ohm

Three-wire RTDs(with J0 module): Pt100, Cu50,0~80ohm,0~400ohm

Linear Mv voltage(with J1 module): 0~100Mv, 0~20mV, 0~60Mv etc

Linear voltage(with J3 module):0~1V,0~3V,0~5V,1~5V

Linear Current:0~12Ma,0~20mA,4~20mA

Square root extraction calculation(with J3 or J4):1~5V, 4~20mA

Two-wire transmitter inputs(with J5):connect to 4~20Ma two wires transmitter

Input range

K(-100~1300°C), S(0~1700°C), R(0~1700°C), T(-200~+390°C), E(0~1000°C), J(0~1200°C),B(600~1800°C),N(0~1300°C),WRe5-WRe26(0~2300°C)

Pt100(-200~+800°C) , Cu50(-50~+150°C)

Linear input: -1999~+9999 set by user

Temperature drift

≤0.01%FS/°C(typical 50PPM/°C)

Isolation withstanding voltage

Between power, relay contact and signal terminals ≥2300VDC

Between isolated electroweak signal terminals≥ 600VDC

Response time

≤ 1.5 s

Alarm function

High and low alarm, configurable separately for each channel

General specifications

Voltage: support AC85-265V,50/60Hz or DC24V.

Power consumption: ≤3W

Electromagnetic compatibility (EMC) : ±4KV/5KHz according to IEC61000-4-4;

4KV according to IEC61000-4-5.

Operating Ambient : temperature -10~60°C; humidity ≤90%RH







3.Order model code instruction

AI-704M four loop Temperature controller


You will get

AI-704M four loop Temperature controller

Other Products

AI-704M four loop Temperature controller

Company Information

AI-704M four loop Temperature controllerAI-704M four loop Temperature controller

Why choose Yudian?

1)Factory with 25 years experience.

2)Quick delivery ( within 3~5 working days).

3)Retail/Wholesale/OEM/ODM available .

    We expect to cooperate with machinery manufacturers, better price for bulk order.

4)We provide after sales service and technical assistance as per the customers requirement and needs.

FAQ

1. How long will you give me the reply?
we will contact you in 2 hours as soon as possible
2. Could I get samples?
Yes,we have products in stock ,so you can get the samples quickly.
3. How about the quality of the controller?
We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.
4. Could I visit your factory?
Of course,if you need we will help you to visit our factory.
5. If I have paid,when will you help me to produce?
We will start producing immediately after receiving the payment.
