DBMEM1300-500P 1.3MP Digital Polarizing Microscope

Name: DBMEM1300-500P 1.3MP Digital Polarizing Microscope
Brand: Future Optics
SKU: 132584563
Availability: InStock

DBMEM1300-500P 1.3MP Digital Polarizing Microscope thumbnail-1

DBMEM1300-500P 1.3MP Digital Polarizing Microscope photo-1

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Future Optics

Model Number:

DBMEM1300-500P

Contact Supplier Request Quote Chat Now

Hangzhou Future Optics Sci & Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Hangzhou Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Future Optics

Model Number DBMEM1300-500P

Theory Video Microscope

Specifications

1280*1024 active pixels
Built-in achromatic relay lens
Polarizing microscope
Win8,Mac,Linux
Future Win Joe image software

♦Applications:

A polarizing microscope uses polarized light to study anisotropic materials such as identifying crystals or fibers suspended in liquid, identifying minerals in core samples and detecting defects in semiconductors or finding stress points in metal, glass and other materials.

♦Functions:

1. To capture images for living show, for shoot and for video recording;

2. To improve image quality by adjusting the gain, resolution, WB, contras, exposure time, RGB color and Gamma setting;

3. To measure and to compare

♦Benefits:

1. Easy installation, convenient operation;

2. Wide field and bright image;

3. Compatibility with Win/MAC;

4. High resolution image of 1280*1024 for preview, picture shoot and video recording;

5. High frame rate .

♦Quality control:

CE issued by SGS laboratory Verification No. SHEMO0808001971T01C

FC issued by SGS laboratory Verification No.SHEMO081100389IT01C

ROHS issued by POCE laboratory, Verification No.POCE13072325TCR

ISO9001-2008 issued by kunlun certification co., Ltd Verification No. 16814QZ0030R0M

♦Main specifications:

Digital eyepiece	1.3 MP USB digital camera equipped with built-in relay lens
Active resolution of sensor	1280*1024
Sensitivity	1.0V/ lux-sec
Dynamic rage	71.0 dB
Frame rate	17fps@1280*1024
Total magnification (optical eyepiece loaded )	40X, 200X, 400X, 600X
Equivalent magnification of digital eyepiece	45X (17” LCD screen display pixel size: 0.2625mm )
Total magnification (digital eyepiece loaded )	180X, 900X, 1800X, 2700X
Optical eyepiece	Plan eyepiece: 10X-18mm and 10X-20mm; 10X -18mm and 10X-20mm with reticle(0.1mm)
Achromatic objective (DIN45mm)	Infinite strain free achromatic objective:4X/0.1,10X/0.25,20X/0.4, 40X/0.65 (spring loaded tip), 60X/0.8(spring loaded tip)
Condenser	N.A> 1.25 Abbe condenser with Iris diaphragm and filter holder
Analyzer	Rotatable analyzer with lock device
Bertrand lens	Built-in center adjustable Bertrand lens
Viewing head	Binocular head 30 rotatable
Nosepiece	Quadruple nosepiece with positive click stopper
Optical compensator	λ lip , 1 /4 λ lip, Quartz wedge
Revolving round stage	Center adjustable and rotatable , diameter 156 mm with 1 division and 6’increments
Polarizing device	Rotatable polarizer with scale
Illumination	Adjustable halogen bulb 6V / 20W
CD of software	Future Win Joe imaging software with movable reticle
Reticle slide	Calibration micro ruler 10mm / 0.01mm
Packing	Carton size: 54.5cm X 39.5cm X 43.5cm
