Help CenterUL Approved Paper Covered Copper Magnet Wire
Related Products
-
Perfect Performance Insulation Paper for Motor WindingUS$ 9.15 - 9.35MOQ: 400 Kilograms -
UL Paper Covered Copper Electrical Wiring for MotorUS$ 3.5 - 4.76MOQ: 400 Kilograms
-
Nomex Paper Covered Copper WireUS$ 9.15 - 9.35MOQ: 400 Kilograms
-
Class 105 Paper Covered Copper WireUS$ 9.15 - 9.35MOQ: 400 Kilograms
-
Class 220 Paper Covered Copper WireUS$ 9.15 - 9.35MOQ: 400 Kilograms
Specifications
paper covered copper magnet wireSpecification; a 0.8-5.0mm;b 2.0-16mm
Standard: IEC GB NEMA
Feature: uniform wrapping
UL approved paper covered copper magnet wire
Size of paper covered copper magnet wire
a 0.8—5.0mm
b 2.0—16mm
Thermal class of paper covered copper magnet wire
90/105/ 120 /130 /180/ 220
insulation materials of paper covered copper magnet wire
Brief description of paper covered copper magnet wire
| Standards | IEC GB NEMA |
| Insulation Thickness | 0.27mm, 0.33mm, 0.45mm or according the customer requirement |
| Characteristics | Uniform ,Fastness wrapping, tightness, uniformity, without drape |
Manufacturing process of paper covered copper magnet wire
Applications of paper covered copper magnet wire
Reactor. Motor
Oil-immersed Transformer
Generator and other electric devices
Packing
inner packing: different wooden spool according to wire guage
Out packing: wooden cases or according the requirement of customer
Test equipment ensure paper covered copper magnet wire that are qualified
Test report of paper covered copper magnet wire
Name |
paper covered copper magnet wire |
|||
Diameter |
3.6mm*8.5mm |
|||
Standard |
GB/T7673.3-2008 |
|||
Test Item |
Unit |
Technical Requirement |
Test Result |
|
Appearance |
|
Uniform, no missing layer, no wrinkling and cracking |
Ok |
|
Bare Conductor |
a |
mm |
±0.05 |
3.605 |
b |
mm |
±0.07 |
8.495 |
|
Thickness of insulation film |
mm |
0.405----0.45 ----0.50 |
0.48 |
|
springback angle |
° |
The springback Angle of conductors less than 5° |
4.6 |
|
Resistivity (20°C) |
Ω.mm2/m |
≤0.017241 |
0.017160 |
|
Elongation |
% |
a:nominaldiameter(mm) ≤2.5 30% >2.5 32% |
45% |
|
Wrapped overlapped |
mm |
≥2 |
2.3 |
|
package |
|
Meet the export standards |
Ok |
|
Quality Control Result |
|
Ok |
||
Application
11. Best service
1) .Trail order is welcomed, you can test our quality before making large quantity, even though we are wholesales supplier
2). We issued test reports for every shipment.
3). You can enjoy discounting and priority to produce first after you become to be our regular client.
12. Company Advantage
1). About 20 years manufacture experiences.
2). Flat wire Audit by UL Company and BV Company
3). We have a big Quality Control Team and can guarantee the quality and time of delivery
4). Many trade companies place orders from us.
