Help CenterSP Series Shop Crane
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
800-960MM
Rated Loading Capacity:
2000KG
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
800-960MM
Rated Loading Capacity
2000KG
Rated Lifting Moment
945-1340MM
Max. Lifting Load
2000KG
Max. Lifting Height
2410MM
Span
800-960MM
Place of Origin
Shanghai, China
Brand Name
SINOLIFT
Model Number
SP
Specifications
SP series shop crane1. capacity: 500kg - 2000kg
2. brand: SINOLIFT
1. FEATURES
* It has also been overload tested to 125%.
* It is fitted with a three position telescopic jib, double acting quick lifting hand hydraulic pump unit, and a heavy duty swivel hook complete with safety catch.
*The folding mechanism saves on workshop space when not in use and please note this unit is mobile and free standing when folded.
* Pressure relief valve to preventoverloading
* Polyurethane wheels and rollers for stress free operation
* CE marked
2. SPECIFICATIONS
| Model | SP500F | SP1000F | SP2000F | SP2000 | |
| Foldable | Yes | No | |||
| Capacity | kg | 500 | 1000 | 2000 | 2000 |
| Capacity at position | P1 | 500 | 1000 | 2000 | 2000 |
| P2 | 400 | 750 | 1500 | 1500 | |
| P3 | 250 | 500 | 1000 | 1000 | |
| P4 | 150 | 250 | 500 | 500 | |
| A | mm | 1403 | 1650 | 1403 | 1350 |
| B | mm | 200 | 170 | 200 | 185 |
| C | mm | 1710 | 1680 | 1710 | 1620-2320 |
| D | mm | 900 | 1160 | 900 | 1270 |
| E | mm | 180 | 95 | 180 | 225 |
| W1 | mm | 810 | 500 | 810 | 945-1340 |
| W2 | mm | 1015 | 1070 | 1015 | 800-960 |
| H1 | mm | 345 | 550 | 345 | 185 |
| H2 | mm | 1820 | 1785 | 1820 | 1945 |
| H3 | mm | // | 180 | // | 485 |
| H4 | mm | 2240 | 1845 | 2240 | 2410 |
| Net Weight | kg | 75 | 96 | 95 | 113 |
3. PHOTOS
, ,
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2005
Factory Size
Below 1,000 square meters
Total Employees
101 - 200 People
