3.5t Diesel Forklift

Name: 3.5t Diesel Forklift
Brand: sinolift
SKU: 132452723
Availability: InStock

US$ 10,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

sinolift

Shanghai Sinolift Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name sinolift

Model Number CPCD3.5t

Type Other, FORKLIFT

Power Souce Diesel Engine

Rated Loading Capacity 3500kg

Specifications

capacity:3.5~5T,ISUZU engine & automatic transmission

Generals	Manufacture				SINOLIFT FORKLIFT TRUCK
	Model				CPC(D)30-X1		CPC(D)35-X1
					CPC(D)30-X2		CPC(D)35-X2
					CPC(D)30-W1		CPC(D)35-W1
					CPC(D)30-W2		CPC(D)35-W2
	Power type				Diesel
	Rated capacity			kg	3000		3500
	Load center			mm	500
Dimensions	Lift height			mm	3000
	Free lift height			mm	145
	Fork size N×U×L			mm	107012545		107013045
	Fork outside spread Min./Max.			mm	300/1700
	Mast tilt angle α / β			deg	6/12
	Front o-verhang G			mm	501
	Overall	Length to face of fork J		mm	2720
	dimensions	Overall width Q		mm	1225
		Mast lowered		mm	2070
		height C
		Mast extended height A		mm	4272
		Overhead guard height P		mm	2090
	Turning radius W			mm	2460		2540
	Min. right angle aisle width X			mm	2110		2190
Performance	Travel speed (full load/no load)	Hydraulic		km/h	17/19
		Mechanical	1		8.8/9
			11		18.5/20
	Lift speed with load			mm/sec	400		360
	Max. gradeability			%	18		15
	Self weight			kg	4380		4750
Wheel & Tires	Tires	Front			28*9-15-14PR
		Rear			6.50-10-10PR
	Tread	Front Q		mm	1000
		Rear S		mm	970
	Wheelbase			MM	1700
	Ground clearance(no load/full load)		Mast M	mm	110/135
			Frame F		130/135
Drive units & control	Battery			V/AH	2*12/100
	Engine	Apply to truck model			CPC(D)30/35-X1	CPC(D)30/35-X2	CPC(D)-30/35-W1	CPC(D)30/35-W2
		Model			490BPG	495BPG	ISUZU C240PKJ	ISUZU 4JG2
		Rated output		kw/rpm	37/2650	42/2650	34.5/2500	44.9/2450
		Rated torque		N.m/rpm	148/1900	174/1800-2000	139/1800	186.3/1600-1800
		No.of cylinder			4	4	4	4
		Bore×stroke		mm	90*100	95*105	86*102	95.4*107
		Displacement		L	2.54	2.98	2.369	3.059
