Specifications
PSP series electric pallet stacking truck1.Capacity:2500kg
2.Lift height:130mm
PSP series electric pallet stacking truck
1)Features
1.Suitable for factory, workshop and ware house. With ergonomically design, the operator can rely on the brake
rest to reduce fatigue. It can steering the direction at a range of 180 degree. The direction indicator makes the
steering easily and effortless.
2.Drive motor:3.0KW,driving powerful, accelerate fast.
3.High loading capacity,small turning radius, perfect for limited space use.
4.AC driving system and steering system of ZAPI makes the truck perform better in traveling and steering, and ensures long service life of battery.
5.MOSFET AC controller grantees that driving and lifting stably and accurately. Excellent speedchanging system.
2)Specification Date
| Model | PSP25 | |
| Power supply | electric | |
| type of operation | stand on | |
| Capacity /rated load | Q kg | 2500 |
| Load center distance | C mm | 600 |
| Load distance | X mm | 957/1027 |
| Wheelbase | Y mm | 1515/1585 |
| Weight(including battery) | kg | 970/980 |
| Axle loadings laden drive end/load end | kg | 1620/1850 |
| Axle loadings unladen drive end/load end | kg | 780/200 |
| Tires (Rubber,Vulkollan,pneumatic,polyurethane) | polyurethane | |
| Tire size drive end | mm | 254×82 |
| Tire size load end | mm | 84×93 |
| Castor wheels | 149×55 | |
| Wheel number(x=drive wheel) drive end/load end | 1×+2/4 | |
| Track width(front) drive end | b10 mm | 441 |
| Track width(rear) load end | b11 mm | 380/505 |
| Lift height | h3 mm | 130 |
| Tiller height | h14 mm | 1290 |
| Fork height lowered | h13 mm | 85 |
| Overall length | l1 mm | 2025/2095 |
| Length to front face to fork | l2 mm | 875 |
| Overall width | b1 mm | 796 |
| Fork dimensions | s/e/l mm | 60/180/1150(1220) |
| Overall fork width | b5 mm | 560/685 |
| Floor clearance, centre of wheelbase | m2 mm | 25 |
| Working aisle with 800x1200 pallet lengthwise | Ast mm | 2533/2570 |
| Turning radius | Wa mm | 1865/1935 |
3)Photos
4)Workshop
5)Certificate
Shanghai Sinolift Equipment Co., Ltd is a production, design, manufacture, sales and service in one integrated production and trade enterprises. Main types of forklifts, material handling, storage and lifting products, also offer a variety of wire harnesses, TFT rule processing business, and produce a variety of OEM memory cards. Products are used in Germany and Japanese technology, all products passed "TUV", "CE", "GS" and "ISO9001" international quality system certification, the application of new technologies has unique.
6)Terms and Service
| Lead time | 3-4 weeks |
| Packing | Standard export fumigated wooden pallet, foam rubbers |
| Payment term | T/T payment in advance; L/C at sight |
| Lead term | FOB Shanghai or CFR/CIF |
| Warranty period | 12 months |
| Shipping method | by sea or air; by express |
7) Warranty Policy and Service Program
SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.
Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.
If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.
SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items
